SweetLine is a cross-platform, high-performance, and extensible syntax highlighting engine designed for modern code editors and code display scenarios. Built on the Oniguruma regex engine and a finite state machine model, it processes large code files in real-time with accurate syntax highlighting.

• Built on Oniguruma regex engine for fast pattern matching
• Incremental update algorithm that only reanalyzes changed portions, ideal for real-time editor highlighting
• Multi-line state preservation to avoid full document reanalysis
• Scope-based indent guides can be analyzed for the full document or a visible line range without running highlighting first
• Bracket pairs can be analyzed independently for rainbow bracket rendering and partner lookup

• Finite State Machine (FSM) based model supporting complex syntax rule nesting
• Multiple capture group style mapping for fine-grained highlighting control
• SubStates mechanism for handling nested syntax structures (e.g., generics, template parameters)
• Zero-width match support for context-sensitive state transitions

• JSON-based syntax rule configuration – add new language support without writing code
• Variable substitution, fragments (include / includes), and pattern reuse to reduce rule redundancy
• 100+ built-in syntax rule files covering mainstream languages, markup, configuration, template, and domain-specific syntaxes

• Core engine written in C++17
• C API wrapper for easy FFI integration
• Native support for Android (JNI), Java 22 (FFM), Flutter/Dart (FFI), WebAssembly (Emscripten), HarmonyOS (NAPI), .NET/WinForms (P/Invoke), and Apple(iOS/macOS)
• Supports Windows, Linux, macOS, mobile platforms, and other desktop scenarios

┌────────────────────────────────────────────────────────────────────────────────────┐
│                              SweetLine Architecture                               │
├────────────────────────────────────────────────────────────────────────────────────┤
│ Application / Platform Bindings                                                   │
│  Android(JNI) | Java22(FFM) | Flutter(Dart FFI) | .NET/C#(P/Invoke)              │
│  WASM(Emscripten) | HarmonyOS(NAPI) | Apple(iOS/macOS) (Swift/ObjC)                │
│  C API(FFI) | C++ Native API                                                      │
├────────────────────────────────────────────────────────────────────────────────────┤
│                         SweetLine C++ Core (C++17)                                │
│                                                                                    │
│  ┌──────────────────────┐        ┌──────────────────────────────┐                 │
│  │    HighlightEngine   │ -----> │  SyntaxRule Compiler (JSON)  │                 │
│  └──────────┬───────────┘        └──────────────────────────────┘                 │
│             │                                                                      │
│    ┌────────▼─────────┐       ┌──────────────────────┐                            │
│    │   TextAnalyzer   │       │   DocumentAnalyzer   │                            │
│    │   (Full Scan)    │       │   (Incremental)      │                            │
│    └────────┬─────────┘       └──────────┬───────────┘                            │
│             │                            │                                         │
│             │                   ┌────────▼─────────┐                               │
│             │                   │  Document Model  │                               │
│             │                   │ (Managed Text)   │                               │
│             │                   └──────────────────┘                               │
│             │                                                                      │
│             └──────────────┬───────────────────────┘                               │
│                            ▼                                                       │
│          ┌────────────────────────────────────────────────────────────┐            │
│          │ Regex + FSM Runtime (Oniguruma + State Machine)           │            │
│          └──────────────────────────┬─────────────────────────────────┘            │
│                                     ▼                                              │
│              Highlight Result + Scope/Indent Guide Analysis                        │
└────────────────────────────────────────────────────────────────────────────────────┘

#include "highlight.h"
using namespace sweetline;

// 1. Create highlight engine
auto engine = std::make_shared<HighlightEngine>();

// 2. Compile syntax rules
auto rule = engine->compileSyntaxFromFile("syntaxes/java.json");

// 3. Create document object
auto document = std::make_shared<Document>("example.java", R"(
public class HelloWorld {
    public static void main(String[] args) {
        System.out.println("Hello, World!");
    }
}
)");

// 4. Load document and analyze
auto analyzer = engine->loadDocument(document);
auto highlight = analyzer->analyze();

// 5. Iterate highlight results
for (size_t i = 0; i < highlight->lines.size(); i++) {
    auto& line = highlight->lines[i];
    for (auto& span : line.spans) {
        // span.range  - text range (line/column/index)
        // span.style_id - style ID (keyword=1, string=2, ...)
    }
}

// When the document is edited, only reanalyze the changed portion
TextRange change_range { {2, 4}, {2, 8} };
std::string new_text = "modified";
auto new_highlight = analyzer->analyzeIncremental(change_range, new_text);

LineRange visible_range {100, 60};

// Analyze enough lines to cover the requested visible range
auto analyzed_slice = analyzer->analyzeLineRange(visible_range);

// Read only the visible lines from the latest cached highlight result
auto cached_slice = analyzer->getHighlightSlice(visible_range);

// Or combine patch + visible slice in one call
auto updated_slice = analyzer->analyzeIncrementalInLineRange(change_range, new_text, visible_range);

// Indent guides are independent from highlighting and can be sliced to the viewport
auto visible_guides = analyzer->analyzeIndentGuidesInLineRange(visible_range);

// Bracket pairs are also independent from highlighting and can be sliced to the viewport
auto visible_brackets = analyzer->analyzeBracketPairsInLineRange(visible_range);

Use analyzeLineRange() when the renderer needs a visible slice and wants SweetLine to analyze enough lines from the current document state first. Use getHighlightSlice() after analyze() or analyzeIncremental() when the renderer only needs a visible window of lines.

Each platform README is the source of truth for installation, API usage, HighlightEngine.removeDocument(...), and native resource lifecycle guidance.

SweetLine uses JSON to define syntax rules. Here is a simple example:

Routing metadata is file-name based. Use fileName / fileNames for exact base names, fileSuffix / fileSuffixes for suffix matches, and fileNamePattern / fileNamePatterns only when exact names and suffixes are not enough.

{
  "name": "myLanguage",
  "fileSuffixes": [".mylang"],
  "variables": {
    "identifier": "[a-zA-Z_]\\w*"
  },
  "fragments": {
    "commonLiterals": [
      { "pattern": "\"(?:[^\"\\\\]|\\\\.)*\"", "style": "string" },
      { "pattern": "//[^\\n]*", "style": "comment" }
    ]
  },
  "states": {
    "default": [
      {
        "pattern": "\\b(if|else|while|return)\\b",
        "styles": [1, "keyword"]
      },
      { "include": "commonLiterals" }
    ]
  }
}

For complete syntax rule configuration, see the Syntax Rule Configuration Guide.

If you want to add or refine syntax rules more quickly, you can also use the skill in skills/. The recommended entry is:

• sweetline-syntax-profile: the SweetLine syntax-authoring workflow and repository policy for syntax rules, routing, style vocabulary, examples, tests, and demo registration

SweetLine provides a grammar pack covering 100+ language and syntax scenarios, including mainstream programming languages, markup languages, configuration formats, template syntaxes, and specialized grammars.

Both the grammars shipped with the repository and developer-authored custom grammars are compiled through HighlightEngine before use, making it easy to adapt SweetLine to different languages, frameworks, and domain-specific scenarios.

See the syntaxes/ directory for the available grammar set, and the Syntax Rule Configuration Guide for authoring details.

• Pre-compile syntax rules: Compile all required syntax rules at application startup; compiled rules are reusable
• Prefer incremental updates: For editor scenarios, use DocumentAnalyzer incremental analysis instead of full analysis
• Optimize regular expressions: Avoid overly complex backtracking-intensive patterns; use variables to reuse common patterns
• Design state machines carefully: Control the number of states and ensure every state has a clear exit path

SweetLine is released under the MIT License.

We welcome contributions to the SweetLine highlighting engine! If you'd like to participate, feel free to fork the repository, make changes, and submit merge requests. For syntax-related work, we recommend using the skills in skills/ together with the Contributing Guide.
