Experimental terminal UI toolkit using the Compose runtime for state-driven, declarative rendering in terminals; supports interactive components, animations, and graceful out-of-bounds pixel handling during terminal resize.
[!NOTE] This is a fork of JakeWharton/mosaic.
It exists solely to ship the fix from JakeWharton/mosaic#1167 (graceful handling of out-of-bounds pixel access during terminal resize) as a published artifact.
Compared to upstream it is Kotlin/Native only — all JVM targets (including the JNI and Zig tooling) have been removed. It is published as
es.jvbabi:mosaic-fork-*purely for use by Julius-Babies/werkbank and is not intended as a general-purpose replacement for upstream Mosaic. Use the original project unless you specifically need this fix on native targets.
An experimental tool for building console UI in Kotlin using the Jetpack Compose compiler/runtime. Inspired by Ink.
Jump to: Introduction | Usage | Samples | FAQ | License
The entrypoint to Mosaic is the runMosaic function.
The lambda passed to this function is responsible for both output and performing work.
suspend fun main() = runMosaic {
Text("The count is: 0")
}To change the output dynamically we can use local properties to hold state. Let's update our counter to actually count to 20.
suspend fun main() = runMosaic {
var count by remember { mutableIntStateOf(0) }
Text("The count is: $count")
LaunchedEffect(Unit) {
for (i in 1..20) {
delay(250.milliseconds)
count = i
}
}
}(Note: You may need to add imports for androidx.compose.runtime.getValue and import androidx.compose.runtime.setValue manually.)
That is the most basic sample of Mosaic. From there, the limit is only your imagination.
(Note: graphs in the above have rendering problems due to asciinema/agg which do not appear in the real output)
Mosaic is a library for Compose, and it relies on JetBrains' Kotlin Compose plugin to be present for use.
Any module which wants to call runMosaic or define @Composable functions for use with Mosaic must have this plugin applied.
For more information, see the JetBrains Compose compiler documentation.
Mosaic itself can then be added like any other dependency:
dependencies {
implementation("es.jvbabi:mosaic-fork-runtime:0.20.1")
}Documentation is available at jakewharton.github.io/mosaic/docs/0.x/.
repository {
mavenCentral()
maven {
url 'https://central.sonatype.com/repository/maven-snapshots/'
}
}
dependencies {
implementation("es.jvbabi:mosaic-fork-runtime:0.21.0-SNAPSHOT")
}Snapshot documentation is available at jakewharton.github.io/mosaic/docs/latest/.
Run ./gradlew installDist to build the sample binaries.
Counter: A simple increasing number from 0 until 20.
./samples/counter/build/install/counter/bin/counter
Demo: A playground for demonstrating many features of Mosaic.
./samples/demo/build/install/demo/bin/demo
Jest: Example output of a test framework (such as JS's 'Jest').
./samples/jest/build/install/jest/bin/jest
Robot: An interactive, game-like program with keyboard control.
./samples/robot/build/install/robot/bin/robot
rrtop: An example inspired by rrtop.
./samples/rrtop/build/install/rrtop/bin/rrtop
snake: Snake game.
./samples/snake/build/install/snake/bin/snake
Compose is, at its core, a general-purpose compiler and runtime to do state tracking and tree node and property manipulation. This can be used on any platform supported by Kotlin for any kind of state or with any tree. It's an amazing piece of technology.
Compose UI is the modern UI toolkit for Android which also runs on the desktop, iOS, and the web. The lack of differentiation between these two technologies has unfortunately caused Compose UI to overshadow the core under the single "Compose" moniker in an unforced marketing error.
Other examples of non-Compose UI-based Compose projects are Cash App's Redwood, JetBrains' Compose HTML, or Google's Jetpack Glance.
Running within Gradle or IntelliJ IDEA will not work. These tools do not provide access to the TTY in order to be interactive. And for non-interactive programs, both will strip ANSI control characters which prevent Mosaic from redrawing over a previous frame. The output will likely just render in successive lines instead.
Run your programs directly in a terminal emulator–no IDE and no Gradle.
Copyright 2020 Jake Wharton
Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
