Offers a camera solution for developing applications, featuring camera preview, image capture, and local image saving. Includes plugin-based API for extensibility and QR code scanning.
A modern camera library for Compose Multiplatform supporting Android, iOS, and Desktop with a unified API.
takePictureToFile()
Add dependencies to your build.gradle.kts:
dependencies {
// Core library
implementation("io.github.kashif-mehmood-km:camerak:0.2.0")
// Optional plugins
implementation("io.github.kashif-mehmood-km:image_saver_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:qr_scanner_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:ocr_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:video_recorder_plugin:0.3")
}Add to your libs.versions.toml:
[versions]
camerak = "0.2.0"
[libraries]
camerak = { module = "io.github.kashif-mehmood-km:camerak", version.ref = "camerak" }
camerak-image-saver = { module = "io.github.kashif-mehmood-km:image_saver_plugin", version.ref = "camerak" }
camerak-qr-scanner = { module = "io.github.kashif-mehmood-km:qr_scanner_plugin", version.ref = "camerak" }
camerak-ocr = { module = "io.github.kashif-mehmood-km:ocr_plugin", version.ref = "camerak" }
camerak-video-recorder = { module = "io.github.kashif-mehmood-km:video_recorder_plugin", version.ref = "camerak" }Then in your build.gradle.kts:
dependencies {
implementation(libs.camerak)
implementation(libs.camerak.image.saver)
implementation(libs.camerak.qr.scanner)
implementation(libs.camerak.ocr)
implementation(libs.camerak.video.recorder)
}Android - Add to AndroidManifest.xml:
<uses-permission android:name="android.permission.CAMERA" />
<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" />
<uses-permission android:name="android.permission.RECORD_AUDIO" /> <!-- Required for video recording with audio -->iOS - Add to Info.plist:
<key>NSCameraUsageDescription</key>
<string>Camera access required for taking photos</string>
<key>NSPhotoLibraryAddUsageDescription</key>
<string>Photo library access required for saving images</string>
<key>NSMicrophoneUsageDescription</key>
<string>Microphone access required for video recording</string>The library now uses reactive state management with StateFlow for a seamless Compose experience:
@Composable
fun CameraScreen() {
val scope = rememberCoroutineScope()
// Create plugins
val imageSaverPlugin = rememberImageSaverPlugin(config = ImageSaverConfig(isAutoSave = true))
val qrScannerPlugin = rememberQRScannerPlugin()
val ocrPlugin = rememberOcrPlugin()
// Create camera state - all configuration and plugins handled here
val cameraState by rememberCameraKState(
config = CameraConfiguration(
cameraLens = CameraLens.BACK,
flashMode = FlashMode.OFF,
aspectRatio = AspectRatio.RATIO_16_9,
),
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(imageSaverPlugin)
stateHolder.attachPlugin(qrScannerPlugin)
stateHolder.attachPlugin(ocrPlugin)
},
)
// Render based on state
when (cameraState) {
is CameraKState.Initializing -> CircularProgressIndicator()
is CameraKState.Ready -> {
val readyState = cameraState as CameraKState.Ready
val controller = readyState.controller
val uiState = readyState.uiState
CameraPreviewView(
controller = controller,
modifier = Modifier.fillMaxSize(),
)
// UI elements overlay the camera
Button(
onClick = {
scope.launch {
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
println("Saved: ${result.filePath}")
}
is ImageCaptureResult.Error -> {
println("Error: ${result.exception.message}")
}
}
}
},
modifier = Modifier.align(Alignment.BottomCenter)
) {
Text("Capture Photo")
}
}
is CameraKState.Error -> {
val error = cameraState as CameraKState.Error
Text("Camera Error: ${error.message}")
}
}
}Creates a reactive camera state holder that manages all camera operations, plugin lifecycle, and state:
@Composable
expect fun rememberCameraKState(
config: CameraConfiguration = CameraConfiguration(),
setupPlugins: suspend (CameraKStateHolder) -> Unit = {},
): State<CameraKState>Returns: State<CameraKState> with the following state variants:
sealed class CameraKState {
data object Initializing : CameraKState()
data class Ready(val controller: CameraController, val uiState: CameraUIState) : CameraKState()
data class Error(val exception: Exception, val message: String, val isRetryable: Boolean = true) : CameraKState()
}State Lifecycle:
Initializing - Camera starting, permissions requested, hardware initializingReady - Camera operational, all plugins auto-activated, ready for capture. Provides controller and uiState.Error - Initialization failed, camera unavailable, permissions denied. Includes message and isRetryable flag.| Platform | Min Version | Backend |
|---|---|---|
| Android | API 21+ | CameraX |
| iOS | iOS 13.0+ | AVFoundation |
| Desktop | JDK 11+ | JavaCV |
Configure camera behavior via the CameraConfiguration data class passed to rememberCameraKState():
val cameraState by rememberCameraKState(
config = CameraConfiguration(
// Camera selection
cameraLens = CameraLens.BACK, // FRONT or BACK
// Visual settings
aspectRatio = AspectRatio.RATIO_16_9, // 4:3, 16:9, 9:16, 1:1
targetResolution = 1920 to 1080, // Optional specific resolution
// Flash control
flashMode = FlashMode.AUTO, // ON, OFF, AUTO
// Torch control
torchMode = TorchMode.OFF, // ON, OFF, AUTO
// Image output
imageFormat = ImageFormat.JPEG, // JPEG or PNG
directory = Directory.PICTURES, // PICTURES, DCIM, DOCUMENTS
returnFilePath = true,
// Quality
qualityPrioritization = QualityPrioritization.BALANCED,
// iOS only: Advanced camera device types
cameraDeviceType = CameraDeviceType.DEFAULT,
// Options: DEFAULT, WIDE_ANGLE, ULTRA_WIDE, TELEPHOTO, MACRO
),
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(imageSaverPlugin)
stateHolder.attachPlugin(qrScannerPlugin)
stateHolder.attachPlugin(ocrPlugin)
},
)| Property | Type | Default | Description |
|---|---|---|---|
cameraLens |
CameraLens |
BACK |
Front or back camera |
aspectRatio |
AspectRatio |
RATIO_16_9 |
4:3, 16:9, 9:16, or 1:1 |
targetResolution |
Pair<Int, Int>? |
null |
Specific width x height |
flashMode |
FlashMode |
OFF |
ON, OFF, or AUTO |
torchMode |
TorchMode |
OFF |
ON, OFF, or AUTO |
imageFormat |
ImageFormat |
JPEG |
JPEG or PNG |
directory |
Directory |
PICTURES |
PICTURES, DCIM, or DOCUMENTS |
returnFilePath |
Boolean |
true |
Whether to return file path in capture result |
qualityPrioritization |
QualityPrioritization |
BALANCED |
Capture quality vs speed tradeoff |
cameraDeviceType |
CameraDeviceType |
DEFAULT |
iOS: DEFAULT, WIDE_ANGLE, ULTRA_WIDE, TELEPHOTO, MACRO |
Access runtime camera control via the CameraController:
when (cameraState) {
is CameraKState.Ready -> {
val controller = (cameraState as CameraKState.Ready).controller
// Zoom
controller.setZoom(2.5f)
val maxZoom = controller.getMaxZoom()
val currentZoom = controller.getZoom()
// Flash
controller.setFlashMode(FlashMode.ON)
controller.toggleFlashMode() // Cycles: OFF -> ON -> AUTO
val mode = controller.getFlashMode()
// Torch (continuous light)
controller.setTorchMode(TorchMode.ON)
controller.toggleTorchMode()
// Camera lens
controller.toggleCameraLens() // Switches between FRONT/BACK
}
}Standard video aspect ratios for different use cases:
AspectRatio.RATIO_4_3 // Standard (old phones, broadcasts)
AspectRatio.RATIO_16_9 // Widescreen (most common)
AspectRatio.RATIO_9_16 // Vertical stories (Instagram, TikTok)
AspectRatio.RATIO_1_1 // Square (Instagram feed)ImageFormat.JPEG // Lossy compression, smaller files, web-ready
ImageFormat.PNG // Lossless compression, larger files, transparency supportCameraK uses an auto-activating plugin system. Plugins are attached via the setupPlugins lambda in rememberCameraKState() and automatically activate when the camera reaches the Ready state. This eliminates manual lifecycle management and provides clean reactive patterns.
How Plugins Work:
setupPlugins lambda calling stateHolder.attachPlugin(...) in rememberCameraKState()
plugin.onAttach(stateHolder) when mountingstateHolder.cameraState and auto-activates when Ready
onDetach() (automatic cleanup)Automatically saves captured images with customizable naming and storage location.
val imageSaverPlugin = rememberImageSaverPlugin(
config = ImageSaverConfig(
isAutoSave = false, // Manual save vs. auto-save on capture
prefix = "MyApp", // Filename prefix
directory = Directory.PICTURES, // Storage directory
customFolderName = "MyAppPhotos" // Android: custom folder in app directory
)
)Images automatically saved when camera captures:
val imageSaverPlugin = rememberImageSaverPlugin(
config = ImageSaverConfig(isAutoSave = true)
)
// Add to camera state
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(imageSaverPlugin)
},
)
// Capture automatically saves
when (cameraState) {
is CameraKState.Ready -> {
val controller = (cameraState as CameraKState.Ready).controller
scope.launch {
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
// Already auto-saved by plugin
println("File saved: ${result.filePath}")
}
}
}
}
}val imageSaverPlugin = rememberImageSaverPlugin(
config = ImageSaverConfig(isAutoSave = false)
)
// Manual save
when (cameraState) {
is CameraKState.Ready -> {
val controller = (cameraState as CameraKState.Ready).controller
scope.launch {
when (val result = controller.takePicture()) {
is ImageCaptureResult.Success -> {
imageSaverPlugin.saveImage(
byteArray = result.byteArray,
imageName = "Photo_${System.currentTimeMillis()}"
)
}
}
}
}
}| Directory | Android Path | iOS Path |
|---|---|---|
PICTURES |
/DCIM/ or Pictures/
|
Photos app |
DCIM |
DCIM/ |
Photos app |
DOCUMENTS |
Documents/ |
Files > Documents |
Real-time QR code detection from camera frames. Results are delivered through CameraKEvent.QRCodeScanned events via the events SharedFlow on CameraKStateHolder.
val qrScannerPlugin = rememberQRScannerPlugin()
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(qrScannerPlugin)
},
)
// Observe QR code results
LaunchedEffect(Unit) {
qrScannerPlugin.getQrCodeFlow().collect { qrCode ->
println("QR Code: $qrCode")
}
}// Start scanning (called automatically on camera ready)
qrScannerPlugin.startScanning()
// Pause scanning (useful after detecting a code)
qrScannerPlugin.pauseScanning()
// Resume scanning
qrScannerPlugin.resumeScanning()
// Get scan results via flow
LaunchedEffect(Unit) {
qrScannerPlugin.getQrCodeFlow()
.distinctUntilChanged()
.collectLatest { qrCode ->
println("QR Code: $qrCode")
qrScannerPlugin.pauseScanning()
// Process result...
delay(2000)
qrScannerPlugin.resumeScanning()
}
}Optical Character Recognition - detects and extracts text from camera frames. Results are delivered through CameraKEvent.TextRecognized events via the events SharedFlow on CameraKStateHolder.
val ocrPlugin = rememberOcrPlugin()
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(ocrPlugin)
},
)
// Observe recognized text events
LaunchedEffect(Unit) {
stateHolder.events
.filterIsInstance<CameraKEvent.TextRecognized>()
.collect { event ->
println("Detected text: ${event.text}")
}
}// Start recognition (called automatically on camera ready)
ocrPlugin.startRecognition()
// Stop recognition
ocrPlugin.stopRecognition()Record video with configurable quality, audio support, pause/resume, and optional max duration. Results are delivered through CameraKEvent recording events via the recordingEvents SharedFlow on the plugin.
VideoConfiguration(
quality = VideoQuality.FHD, // SD, HD, FHD, UHD
enableAudio = true, // Record audio with video
maxDurationMs = 0L, // 0 = unlimited, or set a limit in milliseconds
outputDirectory = null, // null = platform default
filePrefix = "VID", // Filename prefix
)| Quality | Resolution | Bitrate |
|---|---|---|
SD |
640x480 | 1.5 Mbps |
HD |
1280x720 | 5 Mbps |
FHD |
1920x1080 | 10 Mbps |
UHD |
3840x2160 | 50 Mbps |
val videoRecorderPlugin = rememberVideoRecorderPlugin(
config = VideoConfiguration(
quality = VideoQuality.FHD,
enableAudio = true,
maxDurationMs = 300_000L, // 5-minute limit
),
)
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(videoRecorderPlugin)
},
)// Start recording
videoRecorderPlugin.startRecording()
// Start recording to a custom output directory
videoRecorderPlugin.startRecording(outputDirectory = "/path/to/directory")
// Stop recording
videoRecorderPlugin.stopRecording()// Pause the active recording
videoRecorderPlugin.pauseRecording()
// Resume a paused recording
videoRecorderPlugin.resumeRecording()LaunchedEffect(videoRecorderPlugin) {
videoRecorderPlugin.recordingEvents.collect { event ->
when (event) {
is CameraKEvent.RecordingStarted -> {
println("Recording started: ${event.filePath}")
}
is CameraKEvent.RecordingStopped -> {
when (event.result) {
is VideoCaptureResult.Success -> {
val result = event.result as VideoCaptureResult.Success
println("Saved: ${result.filePath}, duration: ${result.durationMs}ms")
}
is VideoCaptureResult.Error -> {
println("Error: ${(event.result as VideoCaptureResult.Error).exception.message}")
}
}
}
is CameraKEvent.RecordingFailed -> {
println("Recording failed: ${event.exception.message}")
}
is CameraKEvent.RecordingMaxDurationReached -> {
println("Max duration reached: ${event.durationMs}ms")
}
else -> {}
}
}
}// Check if currently recording
val isRecording = videoRecorderPlugin.isRecording
// Check if recording is paused
val isPaused = videoRecorderPlugin.isPaused
// Get elapsed recording duration in milliseconds
val durationMs = videoRecorderPlugin.recordingDurationMsPlugins implement simple lifecycle interface:
interface CameraKPlugin {
fun onAttach(stateHolder: CameraKStateHolder)
fun onDetach()
}@Stable
class CustomTextPlugin : CameraKPlugin {
override fun onAttach(stateHolder: CameraKStateHolder) {
// Option 1: Observe state and auto-activate
stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startTextDetection(ready.controller)
}
}
}
override fun onDetach() {
// Cleanup: cancel jobs, close resources
}
private suspend fun startTextDetection(controller: CameraController) {
// Your detection logic here
}
}If you have custom plugins using the deprecated getController() approach:
// OLD (v0.2.0) - Callback based
override fun onAttach(stateHolder: CameraKStateHolder) {
val controller = stateHolder.getController() // Deprecated
startDetection(controller)
}
// NEW (v0.2.0+) - Reactive state based
override fun onAttach(stateHolder: CameraKStateHolder) {
stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startDetection(ready.controller)
}
}
}Main entry point for all camera operations. Created via rememberCameraKState():
class CameraKStateHolder {
// State flows - observe for reactivity
val cameraState: StateFlow<CameraKState> // Initializing/Ready/Error
val uiState: StateFlow<CameraUIState> // Zoom, flash, torch, lens, format, recording state
val events: SharedFlow<CameraKEvent> // Camera events (capture, QR, OCR, etc.)
// Plugin management
fun attachPlugin(plugin: CameraKPlugin)
fun detachPlugin(plugin: CameraKPlugin)
val pluginScope: CoroutineScope // For plugin lifecycle operations
// Camera control
fun captureImage()
fun setZoom(zoom: Float)
fun toggleFlashMode()
fun setFlashMode(mode: FlashMode)
fun toggleTorchMode()
fun setTorchMode(mode: TorchMode)
fun toggleCameraLens()
suspend fun initialize()
fun shutdown()
// Video recording
fun startRecording(configuration: VideoConfiguration = VideoConfiguration())
fun stopRecording()
fun pauseRecording()
fun resumeRecording()
// Utilities
suspend fun getReadyCameraController(): CameraController? // Wait until camera ready
fun getController(): CameraController?
}Low-level camera operations returned in CameraKState.Ready:
expect class CameraController {
// Capture operations
suspend fun takePictureToFile(): ImageCaptureResult // Recommended - direct file save
@Deprecated("Use takePictureToFile()")
suspend fun takePicture(): ImageCaptureResult // Legacy - returns ByteArray
// Zoom control
fun setZoom(zoom: Float)
fun getZoom(): Float
fun getMaxZoom(): Float
// Flash control
fun setFlashMode(mode: FlashMode)
fun getFlashMode(): FlashMode?
fun toggleFlashMode()
// Torch control
fun setTorchMode(mode: TorchMode)
fun getTorchMode(): TorchMode?
fun toggleTorchMode()
// Camera selection
fun getCameraLens(): CameraLens?
fun toggleCameraLens()
// Video recording
suspend fun startRecording(configuration: VideoConfiguration = VideoConfiguration()): String
suspend fun stopRecording(): VideoCaptureResult
suspend fun pauseRecording()
suspend fun resumeRecording()
// Session management
fun startSession()
fun stopSession()
fun cleanup()
// Event listeners
fun addImageCaptureListener(listener: (ByteArray) -> Unit)
}Base interface for all plugins:
interface CameraKPlugin {
/**
* Called when plugin attached to camera state holder.
* Use this to observe [CameraKStateHolder.cameraState] and auto-activate.
*/
fun onAttach(stateHolder: CameraKStateHolder)
/**
* Called when plugin detached or component destroyed.
* Cancel all jobs and cleanup resources here.
*/
fun onDetach()
}Result of image capture operations:
sealed class ImageCaptureResult {
data class SuccessWithFile(val filePath: String) : ImageCaptureResult()
data class Success(val byteArray: ByteArray) : ImageCaptureResult() // Deprecated
data class Error(val exception: Exception) : ImageCaptureResult()
}Result of video recording operations:
sealed class VideoCaptureResult {
data class Success(val filePath: String, val durationMs: Long) : VideoCaptureResult()
data class Error(val exception: Exception) : VideoCaptureResult()
}Configuration for video recording:
data class VideoConfiguration(
val quality: VideoQuality = VideoQuality.FHD,
val enableAudio: Boolean = true,
val maxDurationMs: Long = 0L, // 0 = unlimited
val outputDirectory: String? = null, // null = platform default
val filePrefix: String = "VID",
)Events emitted during camera operation:
sealed class CameraKEvent {
data object None : CameraKEvent()
data class ImageCaptured(val result: ImageCaptureResult) : CameraKEvent()
data class CaptureFailed(val exception: Exception) : CameraKEvent()
data class QRCodeScanned(val qrCode: String) : CameraKEvent()
data class TextRecognized(val text: String) : CameraKEvent()
data class PermissionDenied(val permission: String) : CameraKEvent()
data class RecordingStarted(val filePath: String) : CameraKEvent()
data class RecordingStopped(val result: VideoCaptureResult) : CameraKEvent()
data class RecordingFailed(val exception: Exception) : CameraKEvent()
data class RecordingMaxDurationReached(val filePath: String, val durationMs: Long) : CameraKEvent()
}The v0.2.0 release introduces a new Compose-first reactive API. The old callback-based API is deprecated but still supported with a one-year deprecation timeline:
Old callback-based approach:
// OLD - Callback based
CameraPreview(
cameraConfiguration = { /* ... */ },
onCameraControllerReady = { controller ->
// Manual controller management
}
)New reactive approach:
// NEW - Reactive StateFlow based
@Composable
fun CameraScreen() {
val cameraState by rememberCameraKState(
config = CameraConfiguration(
cameraLens = CameraLens.BACK,
flashMode = FlashMode.OFF,
),
)
when (cameraState) {
is CameraKState.Ready -> {
val readyState = cameraState as CameraKState.Ready
val controller = readyState.controller
val uiState = readyState.uiState
// Use controller and uiState here
}
}
}If you need to wait for camera readiness:
scope.launch {
val controller = stateHolder.getReadyCameraController()
if (controller != null) {
// Camera is ready - safe to use
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> { /* ... */ }
is ImageCaptureResult.Error -> { /* ... */ }
}
}
}If you've created custom plugins using the old API:
class MyPlugin : CameraKPlugin {
override fun onAttach(stateHolder: CameraKStateHolder) {
val controller = stateHolder.getController() // Deprecated
// Directly use controller - race condition risk!
startDetection(controller)
}
}Option A - Stream observation (reactive):
class MyPlugin : CameraKPlugin {
private var job: Job? = null
override fun onAttach(stateHolder: CameraKStateHolder) {
job = stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startDetection(ready.controller)
}
}
}
override fun onDetach() {
job?.cancel()
}
}Option B - Suspend until ready:
class MyPlugin : CameraKPlugin {
override fun onAttach(stateHolder: CameraKStateHolder) {
stateHolder.pluginScope.launch {
val controller = stateHolder.getReadyCameraController()
if (controller != null) {
startDetection(controller)
}
}
}
override fun onDetach() {
// Cleanup if needed
}
}The old getController() method is deprecated:
// Warning level (v0.2.0)
@Deprecated(
"Use cameraState.filterIsInstance<Ready>() instead. " +
"Will be removed in v2.0.0",
replaceWith = ReplaceWith(
"pluginScope.launch { cameraState.filterIsInstance<CameraKState.Ready>().collect { ... } }"
),
level = DeprecationLevel.WARNING
)
fun getController(): CameraController?
// Error level (v1.0.0)
// Same method but with DeprecationLevel.ERROR
// Removed (v2.0.0)
// Method no longer existsThe takePicture() method is deprecated in favor of takePictureToFile():
// Deprecated - Manual file handling required
@Deprecated("Use takePictureToFile() instead")
suspend fun takePicture(): ImageCaptureResult
// Recommended - Direct file save, 2-3x faster
suspend fun takePictureToFile(): ImageCaptureResultPerformance Benefit:
takePicture(): ByteArray in memory -> manual file write (slower, ~2-3 seconds)takePictureToFile(): Direct file save (faster, ~0.5-1 second)| Feature | v0.2.0 | v0.2.0+ | Timeline |
|---|---|---|---|
| Callback-based API | Supported | Deprecated | v2.0.0 removal |
| Reactive StateFlow API | N/A | Recommended | Current |
getController() |
Supported | Deprecated | v2.0.0 removal |
takePicture() |
Supported | Deprecated | v2.0.0 removal |
takePictureToFile() |
N/A | Recommended | Current |
| Plugin auto-activation | N/A | Built-in | Current |
rememberCameraKState() |
N/A | New | Current |
See PLUGIN_MIGRATION_GUIDE.md for comprehensive custom plugin migration examples.
// Deprecated (slower, will be removed in v2.0)
when (val result = controller.takePicture()) {
is ImageCaptureResult.Success -> {
val byteArray = result.byteArray
// Manual file save required
}
}
// Recommended (2-3x faster)
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
val filePath = result.filePath
// File already saved
}
}Problem: Plugins try to access camera before it's ready.
Solution: Always observe cameraState and wait for Ready:
// Wrong - immediate access
override fun onAttach(stateHolder: CameraKStateHolder) {
val controller = stateHolder.getController() // Might be null!
startDetection(controller)
}
// Correct - wait for Ready state
override fun onAttach(stateHolder: CameraKStateHolder) {
stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startDetection(ready.controller)
}
}
}Problem: Plugins attached but not starting operations.
Solution: Ensure you're using rememberCameraKState() with setupPlugins:
// Wrong - old callback API
CameraPreview(
onCameraControllerReady = { controller ->
// Auto-activation not supported
}
)
// Correct - new reactive API
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(myPlugin) // Auto-activates when Ready
},
)Problem: Plugins continue running after unmount.
Solution: Cancel jobs in onDetach():
class MyPlugin : CameraKPlugin {
private var job: Job? = null
override fun onAttach(stateHolder: CameraKStateHolder) {
job = stateHolder.pluginScope.launch {
// Collector will auto-cancel on DisposableEffect cleanup
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready -> startDetection(ready.controller) }
}
}
override fun onDetach() {
job?.cancel() // Explicit cleanup
}
}Problem: Scanning active but no codes detected.
Solution: Verify plugin is attached and check that events are being collected:
val qrPlugin = rememberQRScannerPlugin()
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(qrPlugin)
},
)
// Verify codes coming through via events
LaunchedEffect(Unit) {
stateHolder.events
.filterIsInstance<CameraKEvent.QRCodeScanned>()
.collect { event ->
println("QR Code detected: ${event.qrCode}")
}
}Problem: Text recognition accuracy low on camera stream.
Solution: Use high-resolution images for recognition:
// Better accuracy - from captured image
scope.launch {
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
val file = File(result.filePath)
val byteArray = file.readBytes()
val text = ocrPlugin.recognizeText(byteArray)
}
}
}
// Lower accuracy - real-time stream
// Text recognized events auto-delivered via stateHolder.eventsProblem: "Unresolved reference" for plugin classes.
Solution: Ensure plugins are added to dependencies:
dependencies {
implementation("io.github.kashif-mehmood-km:camerak:0.2.0")
implementation("io.github.kashif-mehmood-km:qr_scanner_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:ocr_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:image_saver_plugin:0.2.0")
}Problem: UI frame rate drops when camera active.
Solution: Use collectAsStateWithLifecycle() for StateFlow and lifecycle-aware collection for SharedFlow:
// Causes recomposition issues
val state by stateHolder.cameraState.collectAsState() // Not lifecycle-aware
// Lifecycle-aware, fewer recompositions
val state by stateHolder.cameraState.collectAsStateWithLifecycle()Enable debug logging to diagnose issues:
// In your initialization code
if (BuildConfig.DEBUG) {
stateHolder.events.collectLatest { event ->
Log.d("CameraK", "Event: $event")
}
}Contributions welcome! Please:
If you find this library useful:
Apache License 2.0
Copyright 2025 Kashif Mehmood
Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
A modern camera library for Compose Multiplatform supporting Android, iOS, and Desktop with a unified API.
takePictureToFile()
Add dependencies to your build.gradle.kts:
dependencies {
// Core library
implementation("io.github.kashif-mehmood-km:camerak:0.2.0")
// Optional plugins
implementation("io.github.kashif-mehmood-km:image_saver_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:qr_scanner_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:ocr_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:video_recorder_plugin:0.3")
}Add to your libs.versions.toml:
[versions]
camerak = "0.2.0"
[libraries]
camerak = { module = "io.github.kashif-mehmood-km:camerak", version.ref = "camerak" }
camerak-image-saver = { module = "io.github.kashif-mehmood-km:image_saver_plugin", version.ref = "camerak" }
camerak-qr-scanner = { module = "io.github.kashif-mehmood-km:qr_scanner_plugin", version.ref = "camerak" }
camerak-ocr = { module = "io.github.kashif-mehmood-km:ocr_plugin", version.ref = "camerak" }
camerak-video-recorder = { module = "io.github.kashif-mehmood-km:video_recorder_plugin", version.ref = "camerak" }Then in your build.gradle.kts:
dependencies {
implementation(libs.camerak)
implementation(libs.camerak.image.saver)
implementation(libs.camerak.qr.scanner)
implementation(libs.camerak.ocr)
implementation(libs.camerak.video.recorder)
}Android - Add to AndroidManifest.xml:
<uses-permission android:name="android.permission.CAMERA" />
<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" />
<uses-permission android:name="android.permission.RECORD_AUDIO" /> <!-- Required for video recording with audio -->iOS - Add to Info.plist:
<key>NSCameraUsageDescription</key>
<string>Camera access required for taking photos</string>
<key>NSPhotoLibraryAddUsageDescription</key>
<string>Photo library access required for saving images</string>
<key>NSMicrophoneUsageDescription</key>
<string>Microphone access required for video recording</string>The library now uses reactive state management with StateFlow for a seamless Compose experience:
@Composable
fun CameraScreen() {
val scope = rememberCoroutineScope()
// Create plugins
val imageSaverPlugin = rememberImageSaverPlugin(config = ImageSaverConfig(isAutoSave = true))
val qrScannerPlugin = rememberQRScannerPlugin()
val ocrPlugin = rememberOcrPlugin()
// Create camera state - all configuration and plugins handled here
val cameraState by rememberCameraKState(
config = CameraConfiguration(
cameraLens = CameraLens.BACK,
flashMode = FlashMode.OFF,
aspectRatio = AspectRatio.RATIO_16_9,
),
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(imageSaverPlugin)
stateHolder.attachPlugin(qrScannerPlugin)
stateHolder.attachPlugin(ocrPlugin)
},
)
// Render based on state
when (cameraState) {
is CameraKState.Initializing -> CircularProgressIndicator()
is CameraKState.Ready -> {
val readyState = cameraState as CameraKState.Ready
val controller = readyState.controller
val uiState = readyState.uiState
CameraPreviewView(
controller = controller,
modifier = Modifier.fillMaxSize(),
)
// UI elements overlay the camera
Button(
onClick = {
scope.launch {
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
println("Saved: ${result.filePath}")
}
is ImageCaptureResult.Error -> {
println("Error: ${result.exception.message}")
}
}
}
},
modifier = Modifier.align(Alignment.BottomCenter)
) {
Text("Capture Photo")
}
}
is CameraKState.Error -> {
val error = cameraState as CameraKState.Error
Text("Camera Error: ${error.message}")
}
}
}Creates a reactive camera state holder that manages all camera operations, plugin lifecycle, and state:
@Composable
expect fun rememberCameraKState(
config: CameraConfiguration = CameraConfiguration(),
setupPlugins: suspend (CameraKStateHolder) -> Unit = {},
): State<CameraKState>Returns: State<CameraKState> with the following state variants:
sealed class CameraKState {
data object Initializing : CameraKState()
data class Ready(val controller: CameraController, val uiState: CameraUIState) : CameraKState()
data class Error(val exception: Exception, val message: String, val isRetryable: Boolean = true) : CameraKState()
}State Lifecycle:
Initializing - Camera starting, permissions requested, hardware initializingReady - Camera operational, all plugins auto-activated, ready for capture. Provides controller and uiState.Error - Initialization failed, camera unavailable, permissions denied. Includes message and isRetryable flag.| Platform | Min Version | Backend |
|---|---|---|
| Android | API 21+ | CameraX |
| iOS | iOS 13.0+ | AVFoundation |
| Desktop | JDK 11+ | JavaCV |
Configure camera behavior via the CameraConfiguration data class passed to rememberCameraKState():
val cameraState by rememberCameraKState(
config = CameraConfiguration(
// Camera selection
cameraLens = CameraLens.BACK, // FRONT or BACK
// Visual settings
aspectRatio = AspectRatio.RATIO_16_9, // 4:3, 16:9, 9:16, 1:1
targetResolution = 1920 to 1080, // Optional specific resolution
// Flash control
flashMode = FlashMode.AUTO, // ON, OFF, AUTO
// Torch control
torchMode = TorchMode.OFF, // ON, OFF, AUTO
// Image output
imageFormat = ImageFormat.JPEG, // JPEG or PNG
directory = Directory.PICTURES, // PICTURES, DCIM, DOCUMENTS
returnFilePath = true,
// Quality
qualityPrioritization = QualityPrioritization.BALANCED,
// iOS only: Advanced camera device types
cameraDeviceType = CameraDeviceType.DEFAULT,
// Options: DEFAULT, WIDE_ANGLE, ULTRA_WIDE, TELEPHOTO, MACRO
),
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(imageSaverPlugin)
stateHolder.attachPlugin(qrScannerPlugin)
stateHolder.attachPlugin(ocrPlugin)
},
)| Property | Type | Default | Description |
|---|---|---|---|
cameraLens |
CameraLens |
BACK |
Front or back camera |
aspectRatio |
AspectRatio |
RATIO_16_9 |
4:3, 16:9, 9:16, or 1:1 |
targetResolution |
Pair<Int, Int>? |
null |
Specific width x height |
flashMode |
FlashMode |
OFF |
ON, OFF, or AUTO |
torchMode |
TorchMode |
OFF |
ON, OFF, or AUTO |
imageFormat |
ImageFormat |
JPEG |
JPEG or PNG |
directory |
Directory |
PICTURES |
PICTURES, DCIM, or DOCUMENTS |
returnFilePath |
Boolean |
true |
Whether to return file path in capture result |
qualityPrioritization |
QualityPrioritization |
BALANCED |
Capture quality vs speed tradeoff |
cameraDeviceType |
CameraDeviceType |
DEFAULT |
iOS: DEFAULT, WIDE_ANGLE, ULTRA_WIDE, TELEPHOTO, MACRO |
Access runtime camera control via the CameraController:
when (cameraState) {
is CameraKState.Ready -> {
val controller = (cameraState as CameraKState.Ready).controller
// Zoom
controller.setZoom(2.5f)
val maxZoom = controller.getMaxZoom()
val currentZoom = controller.getZoom()
// Flash
controller.setFlashMode(FlashMode.ON)
controller.toggleFlashMode() // Cycles: OFF -> ON -> AUTO
val mode = controller.getFlashMode()
// Torch (continuous light)
controller.setTorchMode(TorchMode.ON)
controller.toggleTorchMode()
// Camera lens
controller.toggleCameraLens() // Switches between FRONT/BACK
}
}Standard video aspect ratios for different use cases:
AspectRatio.RATIO_4_3 // Standard (old phones, broadcasts)
AspectRatio.RATIO_16_9 // Widescreen (most common)
AspectRatio.RATIO_9_16 // Vertical stories (Instagram, TikTok)
AspectRatio.RATIO_1_1 // Square (Instagram feed)ImageFormat.JPEG // Lossy compression, smaller files, web-ready
ImageFormat.PNG // Lossless compression, larger files, transparency supportCameraK uses an auto-activating plugin system. Plugins are attached via the setupPlugins lambda in rememberCameraKState() and automatically activate when the camera reaches the Ready state. This eliminates manual lifecycle management and provides clean reactive patterns.
How Plugins Work:
setupPlugins lambda calling stateHolder.attachPlugin(...) in rememberCameraKState()
plugin.onAttach(stateHolder) when mountingstateHolder.cameraState and auto-activates when Ready
onDetach() (automatic cleanup)Automatically saves captured images with customizable naming and storage location.
val imageSaverPlugin = rememberImageSaverPlugin(
config = ImageSaverConfig(
isAutoSave = false, // Manual save vs. auto-save on capture
prefix = "MyApp", // Filename prefix
directory = Directory.PICTURES, // Storage directory
customFolderName = "MyAppPhotos" // Android: custom folder in app directory
)
)Images automatically saved when camera captures:
val imageSaverPlugin = rememberImageSaverPlugin(
config = ImageSaverConfig(isAutoSave = true)
)
// Add to camera state
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(imageSaverPlugin)
},
)
// Capture automatically saves
when (cameraState) {
is CameraKState.Ready -> {
val controller = (cameraState as CameraKState.Ready).controller
scope.launch {
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
// Already auto-saved by plugin
println("File saved: ${result.filePath}")
}
}
}
}
}val imageSaverPlugin = rememberImageSaverPlugin(
config = ImageSaverConfig(isAutoSave = false)
)
// Manual save
when (cameraState) {
is CameraKState.Ready -> {
val controller = (cameraState as CameraKState.Ready).controller
scope.launch {
when (val result = controller.takePicture()) {
is ImageCaptureResult.Success -> {
imageSaverPlugin.saveImage(
byteArray = result.byteArray,
imageName = "Photo_${System.currentTimeMillis()}"
)
}
}
}
}
}| Directory | Android Path | iOS Path |
|---|---|---|
PICTURES |
/DCIM/ or Pictures/
|
Photos app |
DCIM |
DCIM/ |
Photos app |
DOCUMENTS |
Documents/ |
Files > Documents |
Real-time QR code detection from camera frames. Results are delivered through CameraKEvent.QRCodeScanned events via the events SharedFlow on CameraKStateHolder.
val qrScannerPlugin = rememberQRScannerPlugin()
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(qrScannerPlugin)
},
)
// Observe QR code results
LaunchedEffect(Unit) {
qrScannerPlugin.getQrCodeFlow().collect { qrCode ->
println("QR Code: $qrCode")
}
}// Start scanning (called automatically on camera ready)
qrScannerPlugin.startScanning()
// Pause scanning (useful after detecting a code)
qrScannerPlugin.pauseScanning()
// Resume scanning
qrScannerPlugin.resumeScanning()
// Get scan results via flow
LaunchedEffect(Unit) {
qrScannerPlugin.getQrCodeFlow()
.distinctUntilChanged()
.collectLatest { qrCode ->
println("QR Code: $qrCode")
qrScannerPlugin.pauseScanning()
// Process result...
delay(2000)
qrScannerPlugin.resumeScanning()
}
}Optical Character Recognition - detects and extracts text from camera frames. Results are delivered through CameraKEvent.TextRecognized events via the events SharedFlow on CameraKStateHolder.
val ocrPlugin = rememberOcrPlugin()
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(ocrPlugin)
},
)
// Observe recognized text events
LaunchedEffect(Unit) {
stateHolder.events
.filterIsInstance<CameraKEvent.TextRecognized>()
.collect { event ->
println("Detected text: ${event.text}")
}
}// Start recognition (called automatically on camera ready)
ocrPlugin.startRecognition()
// Stop recognition
ocrPlugin.stopRecognition()Record video with configurable quality, audio support, pause/resume, and optional max duration. Results are delivered through CameraKEvent recording events via the recordingEvents SharedFlow on the plugin.
VideoConfiguration(
quality = VideoQuality.FHD, // SD, HD, FHD, UHD
enableAudio = true, // Record audio with video
maxDurationMs = 0L, // 0 = unlimited, or set a limit in milliseconds
outputDirectory = null, // null = platform default
filePrefix = "VID", // Filename prefix
)| Quality | Resolution | Bitrate |
|---|---|---|
SD |
640x480 | 1.5 Mbps |
HD |
1280x720 | 5 Mbps |
FHD |
1920x1080 | 10 Mbps |
UHD |
3840x2160 | 50 Mbps |
val videoRecorderPlugin = rememberVideoRecorderPlugin(
config = VideoConfiguration(
quality = VideoQuality.FHD,
enableAudio = true,
maxDurationMs = 300_000L, // 5-minute limit
),
)
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(videoRecorderPlugin)
},
)// Start recording
videoRecorderPlugin.startRecording()
// Start recording to a custom output directory
videoRecorderPlugin.startRecording(outputDirectory = "/path/to/directory")
// Stop recording
videoRecorderPlugin.stopRecording()// Pause the active recording
videoRecorderPlugin.pauseRecording()
// Resume a paused recording
videoRecorderPlugin.resumeRecording()LaunchedEffect(videoRecorderPlugin) {
videoRecorderPlugin.recordingEvents.collect { event ->
when (event) {
is CameraKEvent.RecordingStarted -> {
println("Recording started: ${event.filePath}")
}
is CameraKEvent.RecordingStopped -> {
when (event.result) {
is VideoCaptureResult.Success -> {
val result = event.result as VideoCaptureResult.Success
println("Saved: ${result.filePath}, duration: ${result.durationMs}ms")
}
is VideoCaptureResult.Error -> {
println("Error: ${(event.result as VideoCaptureResult.Error).exception.message}")
}
}
}
is CameraKEvent.RecordingFailed -> {
println("Recording failed: ${event.exception.message}")
}
is CameraKEvent.RecordingMaxDurationReached -> {
println("Max duration reached: ${event.durationMs}ms")
}
else -> {}
}
}
}// Check if currently recording
val isRecording = videoRecorderPlugin.isRecording
// Check if recording is paused
val isPaused = videoRecorderPlugin.isPaused
// Get elapsed recording duration in milliseconds
val durationMs = videoRecorderPlugin.recordingDurationMsPlugins implement simple lifecycle interface:
interface CameraKPlugin {
fun onAttach(stateHolder: CameraKStateHolder)
fun onDetach()
}@Stable
class CustomTextPlugin : CameraKPlugin {
override fun onAttach(stateHolder: CameraKStateHolder) {
// Option 1: Observe state and auto-activate
stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startTextDetection(ready.controller)
}
}
}
override fun onDetach() {
// Cleanup: cancel jobs, close resources
}
private suspend fun startTextDetection(controller: CameraController) {
// Your detection logic here
}
}If you have custom plugins using the deprecated getController() approach:
// OLD (v0.2.0) - Callback based
override fun onAttach(stateHolder: CameraKStateHolder) {
val controller = stateHolder.getController() // Deprecated
startDetection(controller)
}
// NEW (v0.2.0+) - Reactive state based
override fun onAttach(stateHolder: CameraKStateHolder) {
stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startDetection(ready.controller)
}
}
}Main entry point for all camera operations. Created via rememberCameraKState():
class CameraKStateHolder {
// State flows - observe for reactivity
val cameraState: StateFlow<CameraKState> // Initializing/Ready/Error
val uiState: StateFlow<CameraUIState> // Zoom, flash, torch, lens, format, recording state
val events: SharedFlow<CameraKEvent> // Camera events (capture, QR, OCR, etc.)
// Plugin management
fun attachPlugin(plugin: CameraKPlugin)
fun detachPlugin(plugin: CameraKPlugin)
val pluginScope: CoroutineScope // For plugin lifecycle operations
// Camera control
fun captureImage()
fun setZoom(zoom: Float)
fun toggleFlashMode()
fun setFlashMode(mode: FlashMode)
fun toggleTorchMode()
fun setTorchMode(mode: TorchMode)
fun toggleCameraLens()
suspend fun initialize()
fun shutdown()
// Video recording
fun startRecording(configuration: VideoConfiguration = VideoConfiguration())
fun stopRecording()
fun pauseRecording()
fun resumeRecording()
// Utilities
suspend fun getReadyCameraController(): CameraController? // Wait until camera ready
fun getController(): CameraController?
}Low-level camera operations returned in CameraKState.Ready:
expect class CameraController {
// Capture operations
suspend fun takePictureToFile(): ImageCaptureResult // Recommended - direct file save
@Deprecated("Use takePictureToFile()")
suspend fun takePicture(): ImageCaptureResult // Legacy - returns ByteArray
// Zoom control
fun setZoom(zoom: Float)
fun getZoom(): Float
fun getMaxZoom(): Float
// Flash control
fun setFlashMode(mode: FlashMode)
fun getFlashMode(): FlashMode?
fun toggleFlashMode()
// Torch control
fun setTorchMode(mode: TorchMode)
fun getTorchMode(): TorchMode?
fun toggleTorchMode()
// Camera selection
fun getCameraLens(): CameraLens?
fun toggleCameraLens()
// Video recording
suspend fun startRecording(configuration: VideoConfiguration = VideoConfiguration()): String
suspend fun stopRecording(): VideoCaptureResult
suspend fun pauseRecording()
suspend fun resumeRecording()
// Session management
fun startSession()
fun stopSession()
fun cleanup()
// Event listeners
fun addImageCaptureListener(listener: (ByteArray) -> Unit)
}Base interface for all plugins:
interface CameraKPlugin {
/**
* Called when plugin attached to camera state holder.
* Use this to observe [CameraKStateHolder.cameraState] and auto-activate.
*/
fun onAttach(stateHolder: CameraKStateHolder)
/**
* Called when plugin detached or component destroyed.
* Cancel all jobs and cleanup resources here.
*/
fun onDetach()
}Result of image capture operations:
sealed class ImageCaptureResult {
data class SuccessWithFile(val filePath: String) : ImageCaptureResult()
data class Success(val byteArray: ByteArray) : ImageCaptureResult() // Deprecated
data class Error(val exception: Exception) : ImageCaptureResult()
}Result of video recording operations:
sealed class VideoCaptureResult {
data class Success(val filePath: String, val durationMs: Long) : VideoCaptureResult()
data class Error(val exception: Exception) : VideoCaptureResult()
}Configuration for video recording:
data class VideoConfiguration(
val quality: VideoQuality = VideoQuality.FHD,
val enableAudio: Boolean = true,
val maxDurationMs: Long = 0L, // 0 = unlimited
val outputDirectory: String? = null, // null = platform default
val filePrefix: String = "VID",
)Events emitted during camera operation:
sealed class CameraKEvent {
data object None : CameraKEvent()
data class ImageCaptured(val result: ImageCaptureResult) : CameraKEvent()
data class CaptureFailed(val exception: Exception) : CameraKEvent()
data class QRCodeScanned(val qrCode: String) : CameraKEvent()
data class TextRecognized(val text: String) : CameraKEvent()
data class PermissionDenied(val permission: String) : CameraKEvent()
data class RecordingStarted(val filePath: String) : CameraKEvent()
data class RecordingStopped(val result: VideoCaptureResult) : CameraKEvent()
data class RecordingFailed(val exception: Exception) : CameraKEvent()
data class RecordingMaxDurationReached(val filePath: String, val durationMs: Long) : CameraKEvent()
}The v0.2.0 release introduces a new Compose-first reactive API. The old callback-based API is deprecated but still supported with a one-year deprecation timeline:
Old callback-based approach:
// OLD - Callback based
CameraPreview(
cameraConfiguration = { /* ... */ },
onCameraControllerReady = { controller ->
// Manual controller management
}
)New reactive approach:
// NEW - Reactive StateFlow based
@Composable
fun CameraScreen() {
val cameraState by rememberCameraKState(
config = CameraConfiguration(
cameraLens = CameraLens.BACK,
flashMode = FlashMode.OFF,
),
)
when (cameraState) {
is CameraKState.Ready -> {
val readyState = cameraState as CameraKState.Ready
val controller = readyState.controller
val uiState = readyState.uiState
// Use controller and uiState here
}
}
}If you need to wait for camera readiness:
scope.launch {
val controller = stateHolder.getReadyCameraController()
if (controller != null) {
// Camera is ready - safe to use
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> { /* ... */ }
is ImageCaptureResult.Error -> { /* ... */ }
}
}
}If you've created custom plugins using the old API:
class MyPlugin : CameraKPlugin {
override fun onAttach(stateHolder: CameraKStateHolder) {
val controller = stateHolder.getController() // Deprecated
// Directly use controller - race condition risk!
startDetection(controller)
}
}Option A - Stream observation (reactive):
class MyPlugin : CameraKPlugin {
private var job: Job? = null
override fun onAttach(stateHolder: CameraKStateHolder) {
job = stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startDetection(ready.controller)
}
}
}
override fun onDetach() {
job?.cancel()
}
}Option B - Suspend until ready:
class MyPlugin : CameraKPlugin {
override fun onAttach(stateHolder: CameraKStateHolder) {
stateHolder.pluginScope.launch {
val controller = stateHolder.getReadyCameraController()
if (controller != null) {
startDetection(controller)
}
}
}
override fun onDetach() {
// Cleanup if needed
}
}The old getController() method is deprecated:
// Warning level (v0.2.0)
@Deprecated(
"Use cameraState.filterIsInstance<Ready>() instead. " +
"Will be removed in v2.0.0",
replaceWith = ReplaceWith(
"pluginScope.launch { cameraState.filterIsInstance<CameraKState.Ready>().collect { ... } }"
),
level = DeprecationLevel.WARNING
)
fun getController(): CameraController?
// Error level (v1.0.0)
// Same method but with DeprecationLevel.ERROR
// Removed (v2.0.0)
// Method no longer existsThe takePicture() method is deprecated in favor of takePictureToFile():
// Deprecated - Manual file handling required
@Deprecated("Use takePictureToFile() instead")
suspend fun takePicture(): ImageCaptureResult
// Recommended - Direct file save, 2-3x faster
suspend fun takePictureToFile(): ImageCaptureResultPerformance Benefit:
takePicture(): ByteArray in memory -> manual file write (slower, ~2-3 seconds)takePictureToFile(): Direct file save (faster, ~0.5-1 second)| Feature | v0.2.0 | v0.2.0+ | Timeline |
|---|---|---|---|
| Callback-based API | Supported | Deprecated | v2.0.0 removal |
| Reactive StateFlow API | N/A | Recommended | Current |
getController() |
Supported | Deprecated | v2.0.0 removal |
takePicture() |
Supported | Deprecated | v2.0.0 removal |
takePictureToFile() |
N/A | Recommended | Current |
| Plugin auto-activation | N/A | Built-in | Current |
rememberCameraKState() |
N/A | New | Current |
See PLUGIN_MIGRATION_GUIDE.md for comprehensive custom plugin migration examples.
// Deprecated (slower, will be removed in v2.0)
when (val result = controller.takePicture()) {
is ImageCaptureResult.Success -> {
val byteArray = result.byteArray
// Manual file save required
}
}
// Recommended (2-3x faster)
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
val filePath = result.filePath
// File already saved
}
}Problem: Plugins try to access camera before it's ready.
Solution: Always observe cameraState and wait for Ready:
// Wrong - immediate access
override fun onAttach(stateHolder: CameraKStateHolder) {
val controller = stateHolder.getController() // Might be null!
startDetection(controller)
}
// Correct - wait for Ready state
override fun onAttach(stateHolder: CameraKStateHolder) {
stateHolder.pluginScope.launch {
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready ->
startDetection(ready.controller)
}
}
}Problem: Plugins attached but not starting operations.
Solution: Ensure you're using rememberCameraKState() with setupPlugins:
// Wrong - old callback API
CameraPreview(
onCameraControllerReady = { controller ->
// Auto-activation not supported
}
)
// Correct - new reactive API
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(myPlugin) // Auto-activates when Ready
},
)Problem: Plugins continue running after unmount.
Solution: Cancel jobs in onDetach():
class MyPlugin : CameraKPlugin {
private var job: Job? = null
override fun onAttach(stateHolder: CameraKStateHolder) {
job = stateHolder.pluginScope.launch {
// Collector will auto-cancel on DisposableEffect cleanup
stateHolder.cameraState
.filterIsInstance<CameraKState.Ready>()
.collect { ready -> startDetection(ready.controller) }
}
}
override fun onDetach() {
job?.cancel() // Explicit cleanup
}
}Problem: Scanning active but no codes detected.
Solution: Verify plugin is attached and check that events are being collected:
val qrPlugin = rememberQRScannerPlugin()
val cameraState by rememberCameraKState(
setupPlugins = { stateHolder ->
stateHolder.attachPlugin(qrPlugin)
},
)
// Verify codes coming through via events
LaunchedEffect(Unit) {
stateHolder.events
.filterIsInstance<CameraKEvent.QRCodeScanned>()
.collect { event ->
println("QR Code detected: ${event.qrCode}")
}
}Problem: Text recognition accuracy low on camera stream.
Solution: Use high-resolution images for recognition:
// Better accuracy - from captured image
scope.launch {
when (val result = controller.takePictureToFile()) {
is ImageCaptureResult.SuccessWithFile -> {
val file = File(result.filePath)
val byteArray = file.readBytes()
val text = ocrPlugin.recognizeText(byteArray)
}
}
}
// Lower accuracy - real-time stream
// Text recognized events auto-delivered via stateHolder.eventsProblem: "Unresolved reference" for plugin classes.
Solution: Ensure plugins are added to dependencies:
dependencies {
implementation("io.github.kashif-mehmood-km:camerak:0.2.0")
implementation("io.github.kashif-mehmood-km:qr_scanner_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:ocr_plugin:0.2.0")
implementation("io.github.kashif-mehmood-km:image_saver_plugin:0.2.0")
}Problem: UI frame rate drops when camera active.
Solution: Use collectAsStateWithLifecycle() for StateFlow and lifecycle-aware collection for SharedFlow:
// Causes recomposition issues
val state by stateHolder.cameraState.collectAsState() // Not lifecycle-aware
// Lifecycle-aware, fewer recompositions
val state by stateHolder.cameraState.collectAsStateWithLifecycle()Enable debug logging to diagnose issues:
// In your initialization code
if (BuildConfig.DEBUG) {
stateHolder.events.collectLatest { event ->
Log.d("CameraK", "Event: $event")
}
}Contributions welcome! Please:
If you find this library useful:
Apache License 2.0
Copyright 2025 Kashif Mehmood
Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
