WhatsApp / Telegram-style voice messaging primitives for Compose Multiplatform. A hold-to-record mic with slide-to-lock and slide-to-cancel gestures, plus a playback bubble with waveform and scrubber. One library, every CMP target — audio capture stays BYO.

Every chat app eventually needs the WhatsApp / Telegram voice interaction — and every team rebuilds it from scratch. The gesture choreography is the awkward part: long-press to start, slide up past a threshold to lock, slide left past another threshold to cancel, release with different outcomes per phase, plus the live amplitude waveform and the receive-side playback bubble with seekable scrubber.

voice-message ships that whole flow as a clean Compose Multiplatform primitive. Audio capture (microphone, encoding, file output) stays BYO so the library remains pure Compose and works identically on every CMP target — you wire MediaRecorder / AVAudioRecorder / Web Audio / JavaSound into the state callbacks once and the UX behaves the same everywhere.

gradle/libs.versions.toml:

[libraries]
voice-message       = { module = "io.github.nadeemiqbal:voice-message",       version = "0.3.0" }
# Optional: drop-in mic capture so you do not have to wire MediaRecorder / AVAudioRecorder /
# JavaSound / browser MediaRecorder yourself. Pair with rememberAudioBoundVoiceRecorderState.
voice-message-audio = { module = "io.github.nadeemiqbal:voice-message-audio", version = "0.3.0" }

commonMain dependencies:

kotlin {
    sourceSets {
        commonMain.dependencies {
            implementation(libs.voice.message)
        }
    }
}

val recorderState = rememberVoiceRecorderState(
    onStart = { /* open MediaRecorder / AVAudioRecorder / Web Audio worklet */ },
    onCancel = { /* close + delete the in-progress file */ },
    onSend = { duration, samples ->
        // close the recorder, encode, ship the file
        viewModel.sendVoiceMessage(file, duration, samples)
    },
)

// In your chat input row:
VoiceRecorderInput(
    state = recorderState,
    idlePlaceholder = {
        // your text field goes here — visible while not recording
        ChatTextField(modifier = Modifier.weight(1f))
    },
)

// Feed live amplitudes from your audio source while recording:
LaunchedEffect(Unit) {
    audioCapture.amplitudes.collect { recorderState.pushAmplitude(it) }
}

VoiceMessageBubble(
    samples = message.amplitudes,          // List<Float> 0f..1f
    duration = message.duration,
    isPlaying = playerState.isPlaying(message.id),
    progress = playerState.progress(message.id),
    onPlayPauseToggle = { playerState.toggle(message.id) },
    onSeek = { fraction -> playerState.seek(message.id, fraction) },
    role = if (message.isMine) VoiceMessageRole.Sender else VoiceMessageRole.Receiver,
)

Programmatic control over the recorder

recorderState.start()                                // begin recording
recorderState.pushAmplitude(0.6f)                    // feed mic peaks while recording
recorderState.forceCancel()                          // discard (e.g. on incoming call)
recorderState.sendFromLock()                         // tap the Send button while locked
recorderState.cancelFromLock()                       // tap Cancel while locked
recorderState.phase                                  // VoicePhase.Idle | RecordingHeld | ...
recorderState.elapsed                                // current Duration
recorderState.capturedSamples                        // List<Float> pushed so far

Tuning thresholds

VoiceRecorderInput(
    state = recorderState,
    lockThresholdDp = 100.dp,                        // longer slide-up to lock
    cancelThresholdDp = 60.dp,                       // shorter slide-left to cancel
)

rememberVoiceRecorderState(
    minDuration = 800.milliseconds,                  // tighter tap-vs-hold threshold
    maxDuration = 10.minutes,                        // longer recordings allowed
    onSend = { _, _ -> },
)

Custom colours

VoiceRecorderInput(
    state = recorderState,
    colors = VoiceMessageDefaults.recorderColors().copy(
        micActiveColor = Color(0xFF25D366),          // WhatsApp green
        sendButtonColor = Color(0xFF25D366),
    ),
)

The library never opens a microphone or writes a file. Wire your platform audio in three places:

val recorder = MediaRecorder(context).apply {
    setAudioSource(MediaRecorder.AudioSource.MIC)
    setOutputFormat(MediaRecorder.OutputFormat.MPEG_4)
    setAudioEncoder(MediaRecorder.AudioEncoder.AAC)
    setOutputFile(file)
}
val state = rememberVoiceRecorderState(
    onStart = { recorder.prepare(); recorder.start() },
    onCancel = { recorder.stop(); recorder.release(); file.delete() },
    onSend = { duration, _ -> recorder.stop(); recorder.release(); upload(file, duration) },
)

// Poll the recorder for amplitude:
LaunchedEffect(state.phase) {
    while (state.phase == VoicePhase.RecordingHeld ||
           state.phase == VoicePhase.RecordingLocked ||
           state.phase == VoicePhase.Cancelling) {
        state.pushAmplitude(recorder.maxAmplitude / 32768f)
        delay(50)
    }
}

Sketch — see your favourite Kotlin/Native audio stack for the full glue. The point is that the library's API is the same on every platform; only the actual audio plumbing differs.

Same pattern — open the capture API on onStart, push amplitudes into pushAmplitude, close on onCancel / onSend.

       long-press
Idle ──────────────► RecordingHeld
                      │  │  │
                      │  │  └─ release (elapsed >= minDuration)
                      │  │        └► onSend(duration, samples)
                      │  │
                      │  ├─ slide-up past lockThreshold ► RecordingLocked
                      │  │      ├─ Send tapped ► onSend(…)
                      │  │      └─ Cancel tapped ► onCancel()
                      │  │
                      │  └─ slide-left past cancelThreshold ► Cancelling
                      │           ├─ slide back ► RecordingHeld
                      │           └─ release ► onCancel()
                      │
                      └─ release (elapsed < minDuration) ► Idle (silent, no callback)
                      └─ maxDuration reached ► onSend(…)
                      └─ forceCancel() ► onCancel()

Every transition + every edge case is covered by 31 pure-logic test cases in VoiceMessageLogicTest and 11 UI wiring tests in VoiceMessageUiTest.

• lockThresholdDp / cancelThresholdDp — drag distances for the lock and cancel gestures.
• minDuration / maxDuration — tap-vs-hold threshold and recording length cap.
• colors — full VoiceRecorderColors / VoiceMessageBubbleColors overrides.
• barCount — bar count on VoiceWaveform and VoiceMessageBubble. Lower = chunkier bars.
• role — Sender / Receiver flips the bubble's default tinting.
• idlePlaceholder — the composable slot shown to the left of the mic when not recording.

• v0.3 ("batteries included"): companion artifact voice-message-audio with expect/actual audio adapters that close the BYO gap: Android MediaRecorder, iOS AVAudioRecorder, Desktop javax.sound.sampled, Web MediaRecorder API. Permission helpers and system-interrupt observers included.
• Optional speech-bubble pointer between bubble and avatar.
• Per-bar amplitude animation on append (the bars grow into place).
• 0.5x playback speed and configurable speed sequences.
• Tap-vs-hold distinction (onTap callback) so consumers can toggle into text-only mode on tap.

• voice-message-audio companion artifact: drop-in mic capture for Android, iOS, Desktop, Web. Use rememberAudioBoundVoiceRecorderState { audio, samples -> ... } and skip BYO entirely.
• Critical: recording-cancelled-immediately bug fixed (MicButton is now at one stable slot across phase changes, so its pointer-input modifier survives state.start() recomposition).
• Polished waveform: fixed-width bars (default 3dp) regardless of canvas, count adapts to bubble width, row centered when the canvas is wider than the bar layout.
• Locked-mode strip no longer shows the "Slide to cancel" hint (X / Send buttons are the controls).
• Scrolling live waveform that actually scrolls.
• VoicePhase.Sent removed (was a stuck terminal phase); phase resets to Idle synchronously after onSend.
• RTL handling: slide-to-cancel direction flips in Arabic / Hebrew / Urdu locales.
• Full accessibility: semantics, contentDescription, Role.Button, LiveRegionMode.Polite on the timer.
• Haptic feedback via rememberVoiceHaptics() with per-platform actuals.
