KSensor is a Kotlin Multiplatform library for observing device sensors and system states. Each sensor or state is grouped into its own plugin, allowing you to include only the features you need. This prevents pulling in unnecessary code and permissions.

All data emitted by plugins is wrapped in a KSensorResponse<T> which includes:

• data: The actual sensor or state data.
• platform: The platform type (Android or iOS).
• timestamp: The system time when the data was collected.

Some plugins require system permissions to function. Each plugin exposes a requiredPermissions list indicating what it needs. KSensor provides a PermissionHandler interface in the Core module to help check and request these permissions across platforms.

interface PermissionHandler {
    fun hasPermission(permission: Permission): Boolean
    suspend fun requestPermission(permission: Permission): Boolean
}

You must ensure that the necessary permissions are granted before starting sensor observations. Each plugin section below lists its required permissions.

For Android, you must add the permissions to the Manifest file manually.

The foundation of the library. It is required for all plugins.

Dependency:

implementation("io.github.shadadman:ksensor-core:version")

These plugins provide access to hardware sensors for monitoring movement, environment, and health.

Provides access to hardware sensors for tracking movement.

Dependency:

implementation("io.github.shadadman:ksensor-sensors-motion:version")

Required Permissions:

• Android: ACTIVITY_RECOGNITION (Required for Step Counter)
• iOS: ACTIVITY_RECOGNITION (Motion & Fitness)

Add the following to your AndroidManifest.xml:

• android.permission.ACTIVITY_RECOGNITION

Add the following key to your Info.plist:

• NSMotionUsageDescription: Required for Step Counter and movement detection.

Data Models (Wrapped in KSensorResponse):

• Accelerometer: Accelerometer(values: Vector3)
• Gyroscope: Gyroscope(values: Vector3)
• Step Counter: StepCounter(steps: Int)
• Motion Detector: MotionDetector(type: MotionType) (Detects Walking, Running, Cycling, etc.)

Provides data from sensors that monitor the ambient environment.

Dependency:

implementation("io.github.shadadman:ksensor-sensors-environment:version")

Required Permissions: None

Data Models (Wrapped in KSensorResponse):

• Barometer: Barometer(pressure: Float)
• Light: LightIlluminance(illuminance: Float)
• Proximity: Proximity(distanceInCM: Float, isNear: Boolean)

Provides location services and spatial orientation data.

Dependency:

implementation("io.github.shadadman:ksensor-sensors-positioning:version")

Required Permissions:

• Android/iOS: LOCATION

Add the following to your AndroidManifest.xml:

• android.permission.ACCESS_FINE_LOCATION
• android.permission.ACCESS_COARSE_LOCATION

Data Models (Wrapped in KSensorResponse):

• Location: Location(latitude: Double?, longitude: Double?, altitude: Double?)
• Magnetometer: Magnetometer(values: Vector3)
• Orientation: Orientation(orientation: DeviceOrientation, orientationInt: Int)
• Heading: Heading(magneticHeading: Double, trueHeading: Double, deviceHeading: Double, courseOverGround: Double)
• Location Status: LocationStatus(isLocationOn: Boolean)

Provides high-level data related to user input gestures.

Dependency:

implementation("io.github.shadadman:ksensor-sensors-interaction:version")

Required Permissions: None

Data Models (Wrapped in KSensorResponse):

• Touch Gestures: TouchGestures(x: Float, y: Float, type: TouchGestureType)

Provides access to health related data.

Dependency:

implementation("io.github.shadadman:ksensor-sensors-health:version")

Required Permissions:

• Android/iOS: BODY_SENSORS
• Android/iOS: CAMERA

Add the following to your AndroidManifest.xml:

• android.permission.BODY_SENSORS
• android.permission.CAMERA
• android.permission.health.READ_HEART_RATE (Optional: for Health Connect / API 36+)

Add the following keys to your Info.plist:

• NSCameraUsageDescription: Required for Camera PPG.
• NSHealthUpdateUsageDescription & NSHealthShareUsageDescription: Required for HealthKit data.

Data Models (Wrapped in KSensorResponse):

• Heart Rate: HeartRate(heartRate: Float, source: HeartRateSource, confidence: Float, quality: Float)

The Health plugin implements a robust fallback strategy for heart rate detection on phones:

1. Hardware Sensor:
   • Android: Uses the dedicated hardware heart rate sensor if available.
   • iOS: Uses HealthKit to retrieve the latest heart rate data (often from a paired Apple Watch).
2. Camera PPG: If no hardware sensor data is available, it falls back to Photoplethysmography (PPG).

What is PPG? PPG is a non-invasive method that uses a light source (the phone's flash) and a photodetector (the phone's camera) to measure the volumetric variations of blood circulation. By analyzing the "redness" of your finger over the camera lens, KSensor can estimate user heart rate with high precision using an advanced digital signal processing pipeline (Butterworth filters and adaptive peak detection).

These plugins provide monitoring for various device system and connectivity states.

Provides information about the network connectivity of the device.

Dependency:

implementation("io.github.shadadman:ksensor-states-network:version")

Required Permissions: None

Data Models (Wrapped in KSensorResponse):

• Connectivity: ConnectivityStatus(isConnected: Boolean)
• Active Network: CurrentActiveNetwork(activeNetwork: ActiveNetwork) (Values: WIFI, CELLULAR, NONE)

Provides access to general device system states like battery and volume.

Dependency:

implementation("io.github.shadadman:ksensor-states-system:version")

Required Permissions: None

Data Models (Wrapped in KSensorResponse):

• Battery: BatteryStatus(levelPercent: Int?, chargingState: ChargingState, health: BatteryHealth?, temperatureC: Float?)
• Volume: VolumeStatus(volumePercentage: Int)
• Locale: LocaleStatus(languageCode: String, countryCode: String, fullLocaleString: String, displayName: String, isRTL: Boolean)
• Screen: ScreenStatus(isScreenOn: Boolean)
• Lock: LockStatus(isDeviceLocked: Boolean)
• Power Save: PowerSaveStatus(isPowerSaveMode: Boolean)
• Storage: StorageStatus(totalBytes: Long, usedBytes: Long, freeBytes: Long)

Provides monitoring for BLE connection and discovery events.

Dependency:

implementation("io.github.shadadman:ksensor-states-bluetooth:version")

Required Permissions:

• Android/iOS: BLUETOOTH

Add the following to your AndroidManifest.xml:

• android.permission.BLUETOOTH_SCAN (API 31+)
• android.permission.BLUETOOTH_CONNECT (API 31+)
• android.permission.ACCESS_FINE_LOCATION (Required for discovery on older versions)

Data Models (Wrapped in KSensorResponse):

• BLE Connections: BleConnectionStatus(connectedDevices: List<BleDevice>)
• BLE Discoveries: BleDiscoversStatus(discoveredDevices: List<BleDevice>)
• BLE Device: BleDevice(id: String, name: String)

Tracks the visibility and lifecycle state of the application.

Dependency:

implementation("io.github.shadadman:ksensor-states-lifecycle:version")

Required Permissions: None

Data Models (Wrapped in KSensorResponse):

• App Visibility: AppVisibilityStatus(isAppVisible: Boolean)

1. Register your plugin implementation.
2. Use the KSensor registry to retrieve the plugin and observe its data using Kotlin Flow.

Example to observe using State:

@Composable
fun OrientationSampleUsingState() {
    // Register a plugin
    val plugin = remember {
        KSensor.get<PositioningPlugin>(PluginId.POSITIONING)
            ?: createPositioningPlugin().also { KSensor.register(it) }
    }

    // Use state
    val orientation by plugin.orientation().collectAsState(null)

    println("OrientationData as state: ${orientation?.data}")
}

Example to observe using Effect:

@Composable
fun OrientationSampleUsingEffect() {
    // Register a plugin
    val plugin = remember {
        KSensor.get<PositioningPlugin>(PluginId.POSITIONING)
            ?: createPositioningPlugin().also { KSensor.register(it) }
    }

    // Use effect
    LaunchedEffect(plugin) {
        plugin.orientation().collect {
            println("OrientationData in effect: ${it.data}")
        }
    }
}
