tessera

Tessera (Latin: "small tile piece") — A Compose Multiplatform tile-based high-resolution image viewer

Tessera is a memory-efficient image viewer for Compose Multiplatform. It uses tile-based rendering and platform-native decoders to handle images up to 108MP+ — keeping memory usage up to 95% lower than full-image loading.

• 108MP+ Support — Handles images up to 12000px+ on mobile devices with limited RAM
• Memory Efficient — Subsample decoding + tile-based rendering, only visible tiles in memory
• 1ms Tile Rendering — Skia-optimized tile extraction averages 1-2ms per tile
• Smooth Gestures — 60fps pinch-to-zoom, pan, and double-tap zoom
• Pager Ready — HorizontalPager integration with smart gesture routing (swipe vs pan)
• Compose Native — Built for Compose Multiplatform (not a View wrapper)
• LRU Tile Cache — Automatic eviction with configurable cache size (default: 150 tiles)
• Multiple Image Sources — Network URLs, local files, Android content URIs and resources
• EXIF Orientation — Automatic rotation/mirror correction for all 8 EXIF orientations
• Manual Rotation — User-controlled rotation via ImageRotation enum (None, Rotate90, Rotate180, Rotate270)
• ReadMode — Auto-detect tall/wide images with FitWidth/FitHeight content scaling
• Scroll Indicators — Minimap + scroll bars for zoomed-in navigation (auto-hide)
• Zero Core Dependencies — tessera-core has no external image library dependencies
• Optional Loaders — tessera-coil (KMP) and tessera-glide (Android) companion modules

Add dependencies to your build.gradle.kts:

// Core library (required)
implementation("io.github.bentleypark:tessera-core:<version>")

// Optional: Coil image loader (Android + iOS KMP)
implementation("io.github.bentleypark:tessera-coil:<version>")

// Optional: Glide image loader (Android only)
implementation("io.github.bentleypark:tessera-glide:<version>")

@Composable
fun MyScreen() {
    // Basic usage (built-in NetworkImageLoader)
    TesseraImage(
        imageUrl = "https://example.com/large-image.jpg",
        modifier = Modifier.fillMaxSize()
    )

    // With Coil loader
    val coilLoader = remember { CoilImageLoader(context) }
    TesseraImage(
        imageUrl = "https://example.com/large-image.jpg",
        modifier = Modifier.fillMaxSize(),
        imageLoader = coilLoader
    )

    // Android resource
    TesseraImage(
        imageResId = R.drawable.large_image,
        modifier = Modifier.fillMaxSize()
    )
}

// Kotlin — Basic (built-in IosImageLoader with NSURLSession)
fun MainViewController() = ComposeUIViewController {
    TesseraImage(
        imageUrl = "https://example.com/large-image.jpg",
        modifier = Modifier.fillMaxSize()
    )
}

// Kotlin — With Coil loader
fun MainViewController() = ComposeUIViewController {
    val coilLoader = remember { CoilImageLoader() }
    TesseraImage(
        imageUrl = "https://example.com/large-image.jpg",
        modifier = Modifier.fillMaxSize(),
        imageLoader = coilLoader
    )
}

// Swift — With Coil loader (via TesseraCoil framework)
import TesseraCoil

let coilLoader = CoilImageLoader.companion.create()
MainViewControllerKt.MainViewController(imageLoader: coilLoader)

fun main() = application {
    Window(title = "Tessera Desktop") {
        TesseraImage(
            imageUrl = "https://example.com/large-image.jpg",
            modifier = Modifier.fillMaxSize(),
            showScrollIndicators = true
        )
    }
}

Desktop Gestures:

@OptIn(ExperimentalComposeUiApi::class)
fun main() {
    CanvasBasedWindow(title = "Tessera Web", canvasElementId = "ComposeTarget") {
        TesseraImage(
            imageUrl = "https://example.com/large-image.jpg",
            modifier = Modifier.fillMaxSize()
        )
    }
}

Note: Web support is experimental (Kotlin/Wasm). Unlike Android/iOS/Desktop which use partial or subsampled decoding, the web decoder loads the entire image into memory (no browser partial decode API). Practical limit is ~30MP (2–4 GB JS heap). For larger images, consider server-side tile generation.

Benchmarked on iPhone 7 (A10 Fusion, 2GB RAM, iOS 15.8.5) — 5 runs each:

Benchmarks run on iPhone 7 (A10 Fusion, 2GB RAM, iOS 15.8.5), 5 runs each. All benchmarks use JPEG images. Android uses BitmapRegionDecoder (Tier 1 partial decode) — memory footprint scales with tile size, not image size.

JPEG provides the best performance across all platforms due to its block-based compression structure. PNG, WebP, and other formats are supported but may have higher memory overhead during decoding. GIF animation is not supported — only the first frame is displayed.

Large non-JPEG images (iOS / Desktop): Tessera logs a warning at initialization when a PNG or other non-JPEG image exceeds 30MP. Subsample APIs decode the full image internally before downscaling — a 30MP PNG requires ~120MB during decode before the ~30MB result is cached. For images over 30MP, JPEG is strongly recommended. Filter Logcat/console by tag Tessera to catch these warnings. A callback API (onWarning) may be added in a future release based on user demand.

tessera/
├── tessera-core/      # Core library (Android + iOS + Desktop + Web, zero external deps)
├── tessera-coil/      # Coil 3.x image loader (Android + iOS KMP)
├── tessera-glide/     # Glide 5.x image loader (Android only)
├── sample/            # Android sample app
├── sample-desktop/    # Desktop (JVM) sample app
├── sample-web/        # Web (Wasm) sample app
└── iosApp/            # iOS sample app (SwiftUI + Compose)

TesseraImage (Composable)           <- User-facing API
  |-- Gesture detection
  |-- Canvas tile rendering
  v
TesseraState                        <- State + LRU Cache
  |-- initializeDecoder() on background thread
  |-- applyInitResult() on main thread
  |-- decodeTile() / cacheTile() split for thread safety
  v
TileManager                         <- Grid Calculation
  |-- Zoom level (0-3)
  |-- Visible tile selection
  v
RegionDecoder (expect/actual)       <- Platform Decoding
  |-- Android: BitmapRegionDecoder (true region decoding)
  |-- iOS: CGImageSource subsample + Skia tile extraction
  |-- Desktop: ImageIO subsample cache + getSubimage extraction
  |-- Web: Skia Image.makeFromEncoded + Surface.drawImageRect

Three distinct decoding tiers exist across platforms:

Tier 1 — Partial Decode

• Android: BitmapRegionDecoder requests only the tile region from the decoder. Memory efficiency is highest with JPEG (DCT block structure); PNG and other formats may incur higher internal overhead depending on Android's codec implementation.

Tier 2 — Subsample + Tile Extraction (JPEG optimized)

• iOS: CGImageSource with kCGImageSourceSubsampleFactor decodes at 1/2, 1/4, or 1/8 resolution. Skia drawImageRect extracts tiles at ~1ms each. 108MP JPEG → ~6.7MP in memory (~21MB).
• Desktop: ImageIO with setSourceSubsampling decodes at reduced resolution. Cached BufferedImage serves tiles via getSubimage. Same memory profile as iOS.
• Note: Subsample is only effective for JPEG (DCT block skipping). For PNG and other formats, the decoder loads the full image internally before returning a scaled result — memory savings apply to the cached result only, not during decode. For PNG images over 30MP on iOS/Desktop, this internal full decode may cause OOM before the result is returned. Tessera logs a warning at initialization when a large non-JPEG image is detected.

Tier 3 — Full Decode + Tile Extraction

• Web: Browsers provide no partial image decode API. The entire image is decoded into memory via Image.makeFromEncoded, then tiles are extracted via Skia Surface.drawImageRect.

Web limitation: The 30MP practical limit is a fundamental browser constraint (2–4 GB JS heap), not a Tessera limitation. For images larger than 30MP on web, server-side tile generation is the recommended approach. Web support functions as a zoom viewer rather than a true tile-based viewer.

Android uses BitmapRegionDecoder (true partial decode), so no subsampling step is needed — memory stays at tile level (~0.25MB per 256×256 tile) regardless of image size.

Tessera supports HorizontalPager for image gallery browsing:

val pagerState = rememberPagerState { images.size }

HorizontalPager(state = pagerState) { page ->
    TesseraImage(
        imageUrl = images[page],
        modifier = Modifier.fillMaxSize(),
        enablePagerIntegration = true,  // Enable swipe between pages
        enableDismissGesture = true
    )
}

Gesture behavior with enablePagerIntegration = true:

For long images (webtoons, documents) or wide images (panoramas), use ContentScale to auto-fit:

// Auto-detect: tall → FitWidth, wide → FitHeight, normal → Fit
TesseraImage(
    imageUrl = "https://example.com/webtoon.jpg",
    contentScale = ContentScale.Auto
)

// Force fit to width (vertical scroll)
TesseraImage(
    imageUrl = "https://example.com/document.jpg",
    contentScale = ContentScale.FitWidth
)

# Android build + tests
./gradlew :tessera-core:testDebugUnitTest

# Desktop build + tests
./gradlew :tessera-core:compileKotlinDesktop
./gradlew :tessera-core:desktopTest

# Web (Wasm) build
./gradlew :tessera-core:compileKotlinWasmJs

# Build all modules
./gradlew :tessera-core:assembleDebug :tessera-coil:assembleDebug :tessera-glide:assembleDebug

# iOS framework
./gradlew :tessera-core:linkDebugFrameworkIosSimulatorArm64

# iOS framework with Coil
./gradlew :tessera-coil:linkDebugFrameworkIosSimulatorArm64

# Run sample apps
./gradlew :sample-desktop:run                          # Desktop
./gradlew :sample-web:wasmJsBrowserDevelopmentRun      # Web (localhost:8080)

# All platform tests
./gradlew :tessera-core:allTests

# Run all tests
./gradlew :tessera-core:testDebugUnitTest   # Android (Robolectric)
./gradlew :tessera-core:desktopTest          # Desktop (JVM)

• Android: API 28+ (Android 9)
• iOS: iOS 15+
• Desktop: JDK 21+ (macOS, Windows, Linux)
• Web: Modern browser with WebGL + WebAssembly support
• Kotlin: 2.3.0+
• Compose Multiplatform: 1.8.0+
• JDK: 21+

Contributions are welcome! See CONTRIBUTING.md for development setup, build commands, and guidelines.
