Note: RadialMenu follows Semantic Versioning. Minor versions add features without breaking the API. Major versions may contain breaking changes documented in CHANGELOG.md.

A lightweight Compose Multiplatform radial menu (also known as a circular menu or pie menu) targeting Android and Desktop JVM. It supports multiple trigger modes including long press, right click, and keyboard hold, with drag to select interaction. The menu is built entirely with continuous physics-based selection and is highly inspired by the famous Pinterest context menu.

It features cross-platform haptic feedback, smooth animated menu transitions, and an edge-aware placement geometry ensuring the gesture menu is never clipped off-screen or covered by the user's thumb.

• Compose Multiplatform (supports Android and Desktop).
• Multiple trigger modes: long press, right click, and keyboard hold with automatic per-platform defaults.
• Fully generic items: define your own actions with any number of items (recommended 2 to 8 items).
• Drag to select gesture based item choosing.
• Smart edge-aware angle calculation (ensures menu is never obscured by the finger nor clipped by screen edges).
• Corner edge-hug layout: opt-in L-shaped arrangement when the menu opens in a screen corner with 4+ items.
• Haptic feedback on activation, hover over action, and selection.
• Toggle icon states (for example tracking liked or saved variables and updating icons).
• Item badges: show counts or custom text on each menu item.
• Customizable animations: choose from presets (default, snappy, bouncy, slow) or create your own configuration.
• Dynamic icon scaling on hover for clear visibility.
• Drag direction indicator to help guide the finger.
• RTL layout support: center angle logic mirrors correctly for right-to-left layouts.
• Accessibility: content descriptions, screen reader support, and announcements.
• Zero external dependencies (the published POM declares only kotlin-stdlib; Compose and AndroidX are provided by the consumer).
• ProGuard and R8 safe: includes consumer rules and @Keep annotations.

Full documentation: gawwr4v.github.io/RadialMenu

// Android + Desktop (Compose Multiplatform)
implementation("io.github.gawwr4v:radialmenu:1.0.4")

Recommendation: Use 1.0.4 or newer. 1.0.4 is the first complete Maven Central release with Android, Desktop, and KMP metadata all published correctly.

The published POM only declares kotlin-stdlib. Compose and AndroidX are intentionally treated as provided by the consumer project. If you use the Compose API, include your own Compose dependencies in your app or module.

import io.github.gawwr4v.radialmenu.*

val items = listOf(
    RadialMenuItem(id = 1, icon = painterResource(R.drawable.ic_share), label = "Share"),
    RadialMenuItem(id = 2, icon = painterResource(R.drawable.ic_heart), label = "Like"),
    RadialMenuItem(id = 3, icon = painterResource(R.drawable.ic_bookmark), label = "Save")
)

// Wrap your layout to intercept gestures
Box {
    RadialMenuWrapper(
        items = items,
        onItemSelected = { item ->
            println("Selected: ${item.label}")
        }
    ) {
        Text("Long press me to open radial menu!")
    }

    // Place overlay at root level for fullscreen rendering
    RadialMenuOverlay(items = items)
}

RadialMenuWrapper supports configurable trigger behavior via RadialMenuTriggerMode.

Automatically selects the appropriate trigger per platform:

• Android: LongPress(positionAware = true)
• Desktop: SecondaryClick(positionAware = false)

RadialMenuWrapper(
    items = items,
    onItemSelected = { /* ... */ }
) { Content() }

RadialMenuWrapper(
    items = items,
    onItemSelected = { /* ... */ },
    triggerMode = RadialMenuTriggerMode.LongPress(positionAware = true)
) { Content() }

positionAware = true uses touch-position-aware center angle logic to fan items away from the finger. positionAware = false uses a neutral angle (0f).

RadialMenuWrapper(
    items = items,
    onItemSelected = { /* ... */ },
    triggerMode = RadialMenuTriggerMode.SecondaryClick(positionAware = false)
) { Content() }

• Spawns at cursor position.
• Uses pie-style directional selection.
• With positionAware = false, orientation is neutral and stable.

import androidx.compose.ui.input.key.Key

RadialMenuWrapper(
    items = items,
    onItemSelected = { /* ... */ },
    triggerMode = RadialMenuTriggerMode.KeyboardHold(Key.Q)
) { Content() }

• Menu spawns at screen center.
• Selection is angle-based pie-slice style.
• Flick direction is calibrated from cursor position at key-down (not from menu center).
• Selection commits on key release.
• Edge-hug layout is automatically skipped for center-spawned menus.

<?xml version="1.0" encoding="utf-8"?>
<FrameLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <!-- Your Main Content Here -->

    <!-- Radial Menu Overlay -->
    <io.github.gawwr4v.radialmenu.RadialMenuView
        android:id="@+id/radialMenu"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        app:rm_menuRadius="90dp"
        app:rm_iconSize="32dp"
        app:rm_accentColor="@color/white" />

</FrameLayout>

import io.github.gawwr4v.radialmenu.*

val radialMenu = findViewById<RadialMenuView>(R.id.radialMenu)

val items = listOf(
    RadialMenuItem(id = 1, icon = shareDrawable.toPainter(), label = "Share"),
    RadialMenuItem(id = 2, icon = heartDrawable.toPainter(), label = "Like"),
    RadialMenuItem(id = 3, icon = bookmarkDrawable.toPainter(), label = "Save")
)

radialMenu.setItems(items)
radialMenu.enableEdgeHugLayout = true
radialMenu.triggerMode = RadialMenuTriggerMode.LongPress(positionAware = true)

radialMenu.onItemSelected = { item ->
    when (item.id) {
        1 -> { /* trigger share */ }
        2 -> { radialMenu.setItemActive(2, !item.isActive) }
        3 -> { radialMenu.setItemActive(3, !item.isActive) }
    }
}

Note: RadialMenuView supports LongPress (default) and SecondaryClick triggers. KeyboardHold is accepted for API symmetry but not implemented in the View system; use Compose RadialMenuWrapper for keyboard hold behavior.

RadialMenuView is fully usable from Java via XML or programmatic initialization:

// Java usage example
RadialMenuView menu = findViewById(R.id.radialMenu);

List<RadialMenuItem> items = new ArrayList<>();
items.add(new RadialMenuItem(1, new BitmapPainter(...), ...));
menu.setItems(items);

menu.setOnItemSelected(item -> {
    Toast.makeText(context, "Selected: " + item.getLabel(), Toast.LENGTH_SHORT).show();
    return kotlin.Unit.INSTANCE;
});

menu.setOnTap(() -> {
    Toast.makeText(context, "Tapped!", Toast.LENGTH_SHORT).show();
    return kotlin.Unit.INSTANCE;
});

The Compose API (RadialMenuWrapper) is Kotlin-only. For Java projects, use RadialMenuView in your XML layouts.

The menu dynamically supports any number of items. Items are evenly fanned around the center angle with ICON_SPREAD_DEGREES (45 degrees) spacing.

val items = listOf(
    RadialMenuItem(id = 1, icon = shareIcon, label = "Share"),
    RadialMenuItem(id = 2, icon = heartIcon, label = "Like"),
    RadialMenuItem(id = 3, icon = bookmarkIcon, label = "Save"),
    RadialMenuItem(id = 4, icon = flagIcon, label = "Flag"),
    RadialMenuItem(id = 5, icon = reportIcon, label = "Report")
)

Note: More than 8 items may cause poor UX on small screens. A warning is logged at runtime.

Edge-hug is opt-in. You must pass enableEdgeHugLayout = true to RadialMenuWrapper or set radialMenuView.enableEdgeHugLayout = true on the View to activate it. The default is false.

RadialMenuWrapper(
    items = items,
    onItemSelected = { /* ... */ },
    enableEdgeHugLayout = true
) { Content() }

When the user triggers the menu within EDGE_THRESH_DP (default: 80dp) of two screen edges simultaneously (i.e., a corner), and the menu has 4 or more items, the radial fan cannot fit in the available space. In this case, RadialMenu switches to edge-hug mode:

• Items arrange in an L-shape along the two adjacent edges of the corner.
• The primary edge gets ceil(n/2) items, the secondary edge gets the remainder.
• The corner cell (the exact intersection point) is always left vacant: items start one full step away.
• Selection switches from angle-based to nearest-item distance to match the non-radial arrangement.

If item count is 3 or fewer, the standard radial layout is always used, even in a corner, because 3 items can fit comfortably in a single quadrant.

Configuration (in RadialMenuDefaults):

RadialMenu includes built-in dark and light theme colors.

import io.github.gawwr4v.radialmenu.RadialMenuColors

// Automatic theme-aware colors (follows system dark mode)
RadialMenuOverlay(
    items = items,
    colors = RadialMenuColors.autoTheme()
)

// Force dark
RadialMenuOverlay(
    items = items,
    colors = RadialMenuColors.dark()
)

// Force light
RadialMenuOverlay(
    items = items,
    colors = RadialMenuColors.light()
)

Pass a RadialMenuAnimationConfig to control timing and physics:

RadialMenuOverlay(
    items = items,
    animationConfig = RadialMenuAnimationConfig.bouncy()
)

RadialMenuAnimationConfig(
    openDurationMs = 250,
    closeDurationMs = 150,
    itemScaleDurationMs = 80,
    selectedItemScale = 1.6f,
    enableSpringAnimation = true,
    springDampingRatio = Spring.DampingRatioMediumBouncy,
    springStiffness = Spring.StiffnessMedium
)

Show a count or custom text badge on any item:

RadialMenuItem(id = 1, icon = notifIcon, label = "Notifications", badgeCount = 5)
RadialMenuItem(id = 2, icon = updateIcon, label = "Updates", badgeText = "NEW")

Badges automatically display as a small red circle at the top-right of the item icon. Counts above 99 display as "99+".

A naive radial menu typically spawns symmetrically around the touch point. This can lead to menu items being cut off by the screen edges or pointing directly "downward," thereby obscuring the icons underneath the user's thumb/wrist.

The Solution: RadialMenu calculates a dynamic "center angle" based on the absolute spatial (x,y) location of the touch relative to screen dimensions.

• The base angle smoothly interpolates from 330 degrees (far left edge) to 270 degrees (center) to 210 degrees (far right edge).
• Aggressive edge-boosting ensures menu nodes steeply fan outwards or entirely inward near the absolute edge.
• The top-adjust variable keeps the top 30% boundary clear by flipping the fan downward.
• Overall calculation ensures icons never exceed the safe bounds (only 195 to 345 degrees are permitted for the lower region, 15 to 165 degrees for the upper region).

Menu items always render above all other UI elements, including toolbars, navigation bars, FABs, and bottom sheets. This is handled automatically and requires no setup from the developer.

• Compose: The RadialMenuOverlay renders inside a Popup, which sits above all other composables in the window.
• Android View: When the menu opens, an overlay is attached to the window's decor view, ensuring it draws above the entire view hierarchy. This requires an Activity context. If the context is not an Activity (e.g., Dialog or Service), the overlay falls back to rendering within the current view hierarchy.

Edge-hug zone detection uses the usable content area (excluding system bars) rather than raw screen dimensions, so it only activates at true screen corners, not near in-app UI element edges.

• 💬 GitHub Discussions: questions, ideas, show and tell
• 🐛 Issues: bug reports and feature requests
• 🤝 Contributing: how to contribute
