TV guide UI component for browsing channels and timed events, supporting keyboard and focus navigation, responsive layout, and customizable header/timebar, channel rows and event cells.
This repository contains the implementation of a TV Guide component built using Compose Multiplatform. It supports Android, Desktop, and iOS. The component is designed to provide a user-friendly interface for browsing TV channels and their corresponding events.
Add the dependency to your module's build.gradle.kts:
implementation("dev.sajidali:tvguide:0.0.1")Alternatively, you can clone the repository:
Clone the repository:
git clone https://github.com/sajidalidev/compose-epg-viewer.git
cd compose-epg-viewerOpen the project in your IDE (Android Studio).
Sync the project to download the dependencies.
To integrate the TV Guide component into your application, use the TvGuide composable. You need to create a state using rememberGuideState and pass it to the component.
// Create the state
val state = rememberGuideState()
TvGuide(
state = state,
modifier = Modifier.fillMaxSize()
) {
// Define the Header
Header(
modifier = Modifier.background(Color.LightGray)
) {
// Current Day Indicator
CurrentDay(
width = 250.dp,
modifier = Modifier
) { time: Long ->
// Draw Current Day content
}
// Timebar
Timebar(
modifier = Modifier
) { time: Long ->
// Draw time cell content
Text(text = time.formatToPattern("HH:mm"))
}
}
// Define Channels and Events
Channels(
width = 250.dp,
itemsCount = provider.channelCount, // Number of channels
modifier = Modifier
) { isSelected ->
// 'position' is available in this scope (ChannelRowScope)
ChannelRow(
modifier = Modifier.height(60.dp)
) {
// Draw Channel Cell content (Icon, Name, etc.)
Text(text = "Channel $position")
// Define Events for this channel
Events(
modifier = Modifier,
events = provider.eventsOfChannel(position) // List<Event>
) { event, isEventSelected ->
EventCell(
event = event,
modifier = Modifier
) {
// Draw Event content
Text(text = event.title)
}
}
}
}
// Current Time Indicator
Now(modifier = Modifier) {
Canvas(modifier = Modifier.fillMaxSize()) {
drawLine(
color = Color.Red,
start = Offset(0f, 0f),
end = Offset(0f, size.height),
strokeWidth = 3f
)
}
}
}This project is licensed under the Apache License 2.0.
